300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector
Specifications
Brand Name :
AUO
Model Number :
G220SW01 V0
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
16.7M colors
model :
WLED
style :
wide screen high resolution 1680*1050
brightness :
300cd
connector :
30pin
contrast ratio :
2000:1
working life :
50K hours
Description
  • Panel Brand AUO Panel Model G220SW01 V0
    Panel Size 22.0" Panel Type a-Si TFT-LCD , LCM
    Resolution 1680(RGB)×1050 , WSXGA+ Pixel Format RGB Vertical Stripe
    Display Area 473.76(W)×296.1(H) mm Bezel Opening 477.7(W)×300.1(H) mm
    Outline Size 493.7(W)×320.1(H) mm Surface Antiglare, Hard coating (3H)
    Brightness 300 cd/m² (Typ.) Contrast Ratio 2000:1 (Typ.) (TM)
    Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Mode MVA, Normally Black, Transmissive
    Best View on Symmetry Response Time 15/5 (Typ.)(Tr/Td); 8 (Typ)(G to G)
    Display Colors 16.7M 72% (CIE1931) Lamp Type 6 pcs CCFL , 50K hours , Without Driver
    Frequency 60Hz Touch Screen Without
    Panel Weight 2.95Kgs (Typ.) Application
    Signal Interface LVDS (2 ch, 8-bit) , 30 pins , Connector
    Input Voltage 5.0V (Typ.)
    Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

    300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector300cd/m2 Brightness 22'' Wide Screen AUO Industrial Panel LCD Display with 30 Pin Connector

  • The G220SW01 V0 (Alias: G220SW01 V.0) is a 22.0 inch diagonal a-Si TFT-LCD display panel product from AU Optronics Corp. (hereafter called AUO), with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by einklcd in the following: High Color Gamut, Antiglare Surface, Wide Viewing Angle, Landscape type, Lamp life ≥ 50K hours, Wide Aspect Ratio , Mass production from Nov. 2008. Based on its features, Panelook recommend that this model be applied to Industrial etc. According to the information stored in einklcd this model mass production on Q4, 2008 and last shippment on Q4, 2015, Now this model is discontinued. We inputted this model's specification on Dec 19 2012 for the first time, and the latest update on Jul 7 2015. If you want to embed G220SW01 V0 LCM in your future product, einklcd strongly recommend that you should contact with AUO or it's agent to learn lateast production and specification detail. The G220SW01 V0 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

It's 300cd/m2 lcd MODEL for industrial field use.

All our LCD LED screen monitor module panel products will be full test one by one before sending .
