Innolux 15.6Inch LCD Panel with 1920x1080 Pixels Resolution 450cd/m² Brightness and 40pin Interface Industrial LCD Display
Innolux 15.6Inch LCD Panel with 1920x1080 Pixels Resolution 450cd/m² Brightness and 40pin Interface Industrial LCD Display
Innolux 15.6Inch LCD Panel with 1920x1080 Pixels Resolution 450cd/m² Brightness and 40pin Interface Industrial LCD Display
Innolux 15.6Inch LCD Panel with 1920x1080 Pixels Resolution 450cd/m² Brightness and 40pin Interface Industrial LCD Display
Specifications
Brand Name :
innolux
Model Number :
AT056TN52
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
resolution :
1920*1080pixels
style :
WLED 40P
brightness :
450 CCD M2
color :
16.7M
contrast ratio :
1000 :1
working life :
50K Hours
Description
Innolux 15.6-Inch LCD Panel G156HCE-E01
15.6-inch industrial LCD module featuring 1920*1080 Full HD resolution, 450 cd/m² brightness, and 40-pin eDP interface. Designed for industrial applications and gaming systems with wide operating temperature range and robust construction.
Key Features
  • 15.6-inch diagonal a-Si TFT-LCD display
  • Full HD 1920*1080 resolution (141 PPI)
  • High brightness: 450 cd/m² (typical)
  • 1000:1 contrast ratio
  • WLED backlight with 50,000-hour lifespan
  • eDP 1.2 interface with 40-pin connector
  • Wide viewing angle: 89/89/89/89
  • Industrial temperature range: 0°C to 60°C
  • Anti-glare, hard coating (3H) surface treatment
Technical Specifications
BrandInnolux
Model NumberG156HCE-E01
Panel Typea-Si TFT-LCD, LCM
Active Area344.16 * 193.59 mm
Outline Dimensions351.84 * 208.88 * 6.5 mm (H*V*D)
Pixel FormatRGB Vertical Stripe
Color Depth16.7M colors (72% NTSC)
Response Time14/11 ms (Typ.)
Refresh Rate60Hz
Operating Voltage3.3V (Typ.)
Weight550g (Typ.)
Operating Temperature0°C to 60°C
Storage Temperature-20°C to 70°C
Vibration Resistance1.5G (14.7 m/s²)
Innolux 15.6Inch LCD Panel with 1920x1080 Pixels Resolution 450cd/m² Brightness and 40pin Interface Industrial LCD Display
This model entered mass production in Q2 2020 and is currently in production. For the latest production status and detailed specifications, we recommend contacting Innolux or their authorized agents directly. Product information is subject to change without notice.
