LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
LG 55 LCD TV Panel TFT-LCD Display Panel with 450 CD/M2 Brightness 1920*1080 Resolution and 51pin Connector
Specifications
Brand Name :
LG
Model Number :
LD550EUE-FHB1
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
resolution :
1920*1080
style :
51PIN IPS
brightness :
450 CD/M2
color :
16.7m
contrast ratio :
1100 :1
working life :
50k hours without driver
Description
LG 55" LCD TV Panel LD550EUE-FHB1
High-performance 55-inch LCD display panel featuring 450 cd/m² brightness, 1920*1080 Full HD resolution, and 51-pin LVDS interface. Ideal for digital signage applications with reliable performance and extended lifespan.
LG 55
Product Specifications
Brand LG Display
Model P/N LD550EUE-FHB1
Diagonal Size 55"
Panel Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)*1080, FHD (40PPI)
Pixel Format RGB Vertical Stripe
Active Area 1209.6(W)*680.4(H) mm
Bezel Opening 1214.2(W)*685.0(H) mm
Outline Dimensions 1232(W)*708.9(H)*28.6(D) mm
Surface Treatment Antiglare (Haze 1%), Hard coating (3H)
Luminance 450 cd/m² (Typical)
Contrast Ratio 1100:1 (Typical)
View Direction Symmetry
Response Time 12ms (Typical, G to G)
Viewing Angle 89/89/89/89 (Minimum, CR≥10)
Operating Mode S-IPS, Normally Black, Transmissive
Color Support 16.7M colors, 68% NTSC
Light Source WLED (2 strings), 50K hours lifespan, Without Driver
Weight 13.0/13.7 kg (Typical/Maximum)
Frame Rate 60Hz
Touch Panel Without
Interface Type LVDS (2 channel, 8-bit), 51-pin Connector
Power Supply 12.0V (Typical)
Operating Temperature 0°C to 50°C
Storage Temperature -20°C to 60°C
Application Information
This 55-inch LCD panel is specifically designed for digital signage applications. The panel features landscape/portrait orientation capability, WLED backlight technology with 50,000+ hours lifespan, matte surface treatment, and integrated black bezel design.
Important Note: This model (LD550EUE-FHB1) began mass production in Q1 2015 and was discontinued in Q4 2020. For integration into future products, we strongly recommend contacting LG Display or their authorized distributors for the latest production status and specification details. The information provided here is for reference purposes only and should not be used as the sole basis for decision-making.
