Specifications
Model Number :
V750DK1-KS5
Package :
Original industrial packing
MOQ :
10pcs
Delivery Time :
4-5 working day
Color :
16.7M/1.07B
resolution :
3840*2160pixels UHD
Payment Terms :
T/T,Western Union
working life :
30K hours
Price :
Negotiation
Contrast ratio :
1400:1
Certification :
Rohs,CE,FCC
brightnerss :
450CCD/M2
Supply Ability :
3000pcs per week
touch panel :
without
Brand Name :
LG
Quality :
Brand new Original
Place of Origin :
China
Connector :
97P
Packaging Details :
Industrial packing
Description
Innolux 75-Inch TV LCD Panel Model V750DK1-KS5
Note: This model has been discontinued
UHD 3840*2160 Pixels LCD Display with 380 cd/m² brightness, designed for interactive whiteboards and TV applications.
Innolux 75 Inch LCD Panel with 3840x2160 Pixels UHD Resolution and 380 cd/m² Brightness for Interactive Whiteboard and TV LCD Screen
Product Overview
The Innolux V750DK1-KS5 Rev.C1 is a 75-inch diagonal a-Si TFT-LCD display panel featuring an integral WLED backlight system with LED driver. This panel operates within a temperature range of 0~50°C and stores safely at -20~60°C. Originally mass produced in Q4 2014, this model is now discontinued.
Key Features
  • 120Hz refresh rate with 3D display capability
  • 10-bit color depth displaying 1.07 billion colors
  • Super MVA technology with normally black, transmissive display
  • WLED backlight with 30,000-hour lifespan
  • Matte surface with anti-glare and hard coating (3H)
  • V-by-One 8-lane interface with 56-pin connector
Technical Specifications
Manufacturer Innolux
Model Name V750DK1-KS5 Rev.C1
Display Size 75 inches
Panel Type a-Si TFT-LCD, LCM
Resolution 3840(RGB)*2160 (UHD), 16:9 aspect ratio
Brightness 380 cd/m² (Typical)
Contrast Ratio 4000:1 (Typical)
Viewing Angle 88/88/88/88 (CR≥20)
Response Time 6.5 ms (G to G, Typical)
Display Colors 1.07 billion, 88% NTSC
Display Area 1650.24(W) * 928.26(H) mm
Outline Size 1670.64(W) * 951.66(H) mm
Panel Weight 35.0 kg (Typical)
Interface V-by-One 8 lanes, 56 pins Connector
Input Voltage 12.0V (Typical)
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
Applications
  • TV Sets
  • Interactive Whiteboards
Important Notice: This model's production status is provided for reference only and should not be used as the basis for decision-making. For current production and specification details, please contact Innolux or their authorized distributors.
