BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
Specifications
Model Number :
NE140WUM-N48
Package :
Original industrial packing
Certification :
Rohs,CE,FCC
material :
glass
MOQ :
10pcs
Delivery Time :
4-5 working day
Resolution :
1920*1200pixels
connector :
30P
Payment Terms :
T/T,W,Western Union
color :
16.7m
Price :
Negotiation
contrast ratio :
1200:1
Supply Ability :
3000pcs per week
Working life :
15k hours
screen size :
14inch
Brand Name :
BOE
Quality :
Brand new Original
Place of Origin :
China
Brightness :
300ccd/m2
Packaging Details :
Industrial packing
Touch panel :
without
Description
BOE 14-Inch PC LCD Module NE140WUM-N48 TFT-LCD Display Panel
Product Overview

BOE 14-Inch PC LCD Module NE140WUM-N48 TFT-LCD Display Panel with 1920×1200 pixels resolution, 300 cd/m² brightness, and 30-pin laptop LCD interface.

BOE Technology Group Co., Ltd. NE140WUM-N48 (Product Code: BOE0D8B) is a 14.0-inch diagonal Oxide TFT-LCD display panel product featuring an integral WLED backlight system with LED driver, without touch screen. This model is recommended for laptop applications and features AMD FreeSync technology with eDP1.2 interface.

BOE 14Inch PC LCD Module TFT-LCD Display Panel with 1920x1200 Pixels 300cd/m2 Brightness 30pin Connector
Technical Specifications
Manufacturer BOE Model No. NE140WUM-N48
Screen Size 14.0 inch Screen Type Oxide TFT-LCD, LCM
Number of Dots 1920(RGB)×1200, WUXGA, 16:10 Dot Layout RGB Vertical Stripe
Active Area 301.594×188.496 mm (H×V) Outline Area 307.29×198.85×4.8 mm (H×V×D)
Weight 300g (Max.) Surface Feature Antiglare, Hard coating (3H)
Luminance 300 cd/m² (Typ.) Contrast Ratio 1200 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Display Type ADS, Normally Black, Transmissive
Outline Shape Symmetry Response (ms) 25 (Typ.)(Tr+Td)
Display Colors 16.7M, 48% NTSC Used for Laptop
Refresh Rate 60Hz, AMD FreeSync Backlight 10S6P WLED, 15K hrs, With LED Driver, DC
Signal Type eDP (2 Lanes), eDP1.2, HBR1 (2.7G/lane), 30 pins Connector Touchscreen Without
Voltage Supply 3.3V (Typ.) Max. Ratings Storage Temp. -20 ~ 60 °C
Operating Temp. 0 ~ 50 °C
Additional Information

This model features slim design (PCBA Bent, T≤3.0mm) and general features include WLED Backlight, With LED Driver, Reverse I/F, Matte, FreeSync, eDP1.2, FreeSync, PN P05466-L92.

Note: The production status information provided is for reference only and should not be used as the basis for decision making. We strongly recommend contacting BOE or its distributor for the latest production and specification details.
