8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
Specifications
Model Number :
NL8060BC21-11F
Package :
Original industrial packing
Price :
Negotiation
contrast ratio :
800:1
Certification :
Rohs,CE,FCC
material :
glass
MOQ :
10pcs
Delivery Time :
4-5 working day
Resolution :
800*600pixels
connector :
20P
Payment Terms :
T/T,W,Western Union
color :
262K
Supply Ability :
3000pcs per week
Working life :
70k hours
Brand Name :
NEC
Quality :
Brand new Original
Packaging Details :
Industrial packing
Touch panel :
without
Place of Origin :
China
Brightness :
800ccd/m2
Description
8.4 Inch Industrial LCD Monitor NL8060BC21-11F
8.4-inch diagonal industrial LCD monitor with 800*600 pixels resolution, 800 cd/m² brightness, and 20-pin LVDS interface.
8.4 Inch Industrial LCD Monitor with 800 cd/m² Brightness 800*600 Pixels Resolution and 20pin Connector
The NL8060BC21-11F is an 8.4-inch diagonal a-Si TFT-LCD display panel from NEC LCD Technologies, Ltd., featuring an integral WLED backlight system without backlight driver or touch screen. This industrial-grade monitor operates in temperatures ranging from -30°C to 80°C and withstands vibrations up to 2.0G (19.6 m/s²).
Key Features
  • Wide operating temperature range (-30°C to 80°C)
  • High brightness: 800 cd/m² typical
  • Replaceable lamp with ≥70,000 hours lifespan
  • WLED backlight technology
  • 180° reverse display capability
  • 6/8-bit color depth with ColorXcell technology
Technical Specifications
Parameter Specification
Brand NEC
Model NL8060BC21-11F
Diagonal Size 8.4 inch
Type a-Si TFT-LCD, LCM
Pixel Number 800(RGB)*600, 4:3, SVGA
Pixel Format RGB Vertical Stripe
Active Area 170.4(H)*127.8(V) mm
Physical Size 200(H)*152(V)*8.7(D) mm
Mass 260/280g (Typ./Max.)
Surface Coating Clear, Hard coating (3H)
Luminance 800 cd/m² (Typ.)
Contrast Ratio 800:1 (Typ.)
View Direction 6 o'clock
Response Time 3/15 (Typ.)(Tr/Td) ms
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Operating Mode TN, Normally White, Transmissive
Support Color 262K/16.7M, 40% NTSC
Power Usage 5.0W (Typ.)
Light Source 4 strings WLED, 70K hrs, Without Driver
Frame Rate 60Hz
Touch Panel Without
Interface Type LVDS (1 ch, 6/8-bit), 20 pins Connector
Power Supply 3.3V (Typ.)
Environment Operating Temperature -30 ~ 80°C, Storage Temperature -30 ~ 80°C, Vibration 2.0G (19.6 m/s²)
Application Recommendations
This model is specifically designed for industrial applications requiring robust performance in challenging environmental conditions.
Important Note: The production status information provided is for reference only. For integration into your products, we strongly recommend contacting NEC or their authorized agents for the latest production status and detailed specifications.
