CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
CSOT 55 LCD TV Panel TFT-LCD Display Panel with 500 CD/M2 Brightness 3840*2160 Resolution and 51pin Connector
Specifications
resolution :
3840*2160
Certification :
Rohs,CE,FCC
Package :
Original industrial packing
Model Number :
LD550EQE-FPA2
color :
1.07B
Price :
Negotiation
working life :
50k hours without driver
Supply Ability :
3000pcs per week
brightness :
500 CD/M2
MOQ :
10pcs
Delivery Time :
4-5 working day
contrast ratio :
1100 :1
Payment Terms :
T/T,W,Western Union,MoneyGram
Quality :
Brand new Original
Brand Name :
CSOT
Packaging Details :
Industrial packing
style :
51PIN IPS
Place of Origin :
China
Description
CSOT 55" LCD TV Panel LD550EQE-FPA2
High-performance 55-inch TFT-LCD display panel featuring 500 cd/m² brightness, 3840×2160 UHD resolution, and 51-pin connector. Ideal for digital signage applications with robust industrial specifications.
Product Overview
The CSOT LD550EQE-FPA2 is a 55-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system. This industrial-grade panel operates within 0~50°C and features a 10-bit color depth with matte surface treatment. Recommended for digital signage applications with a backlight life expectancy of ≥50,000 hours.
Technical Specifications
Manufacturer CSOT
Model Number LD550EQE-FPA2
Screen Size 55 inch
Screen Type a-Si TFT-LCD, LCM
Resolution 3840×2160 (UHD), 16:9 aspect ratio
Active Area 1209.6×680.4 mm (H×V)
Brightness 500 cd/m² (Typical)
Contrast Ratio 1100:1 (Typical)
Viewing Angle 89/89/89/89 (CR≥10)
Response Time 8 ms (G to G, Typical)
Display Type IPS, Normally Black, Transmissive
Color Support 1.07 billion colors, 68% NTSC
Power Consumption 91.36W (Typical)
Backlight 3 strings × 2CN WLED, 50K hours life
Signal Interface V-by-One 8 lanes, 51-pin connector
Operating Voltage 12.0V (Typical)
Operating Temperature 0 ~ 50°C
Storage Temperature -20 ~ 60°C
Outline Dimensions 1233.4×706.8×30.1 mm (H×V×D)
Weight 13.9 kg (Typical) / 14.6 kg (Maximum)
Surface Treatment Antiglare (Haze 28%), Hard coating (2H)
CSOT 55
Note: Production status information is for reference only. For latest production and specification details, please contact CSOT or their authorized distributors before making integration decisions.
