Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Specifications
Model Number :
TM070RVHG04-01
Package :
Original industrial packing
MOQ :
10pcs
Delivery Time :
4-5 working day
brightness :
1200CD/M2
Type :
lcm
Brand Name :
Tianma
Quality :
Brand new Original
Packaging Details :
Industrial packing
Size :
7inch
Payment Terms :
T/T,W,Western Union
contrast ratio :
500 :1
Voltage :
3.3V
Supply Ability :
3000pcs per week
working life :
40K Hours
Lamp type :
lcm
Certification :
Rohs,CE,FCC
resolution :
800*480pixels
Price :
Negotiation
color :
262k
model numberer :
TM070RVHG04-01
Place of Origin :
Japan
style :
50PIN IPS
Description
Tianma 7Inch Industrial LCD Display TM070RVHG04-01
Tianma Microelectronics Co., Ltd. TM070RVHG04-01 is a 7.0-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system, featuring PCAP touchscreen technology. Designed for industrial and outdoor high-brightness applications, this display operates within -20°C to 70°C and stores within -30°C to 80°C temperature ranges.
Tianma 7inch Industrial LCD Display with 1200cd/m² Brightness and 800x480 Pixels Resolution TFT-LCD Panel
Technical Specifications
Brand TIANMA
Model TM070RVHG04-01
Diagonal Size 7.0 inch
Type a-Si TFT-LCD, LCM
Pixel Number 800(RGB)×480, 16:9, WVGA
Pixel Format RGB Vertical Stripe
Active Area 154.08(H)×85.92(V) mm
Physical Size 171.5(H)×110.3(V)×7.75(D) mm
Mass 208g (Typ.)
Luminance 1200 cd/m² (Typ.)
Contrast Ratio 500:1 (Typ.)
View Direction 6 o'clock
Response Time 25 ms (Typ.)
Viewing Angle 80/80/60/80 (Typ.)
Operating Mode TN, Normally White, Transmissive
Support Color 262K/16.7M, 50% NTSC
Light Source 6S5P WLED, 40K hrs, Without Driver
Frame Rate 60Hz
Touch Panel PCAP, I²C
Interface Type Parallel RGB (1 ch, 6/8-bit), 50 pins FPC
Power Supply 3.3/10.4/16.0/-7.0V (Typ.)
Operating Temperature -20°C to 70°C
Storage Temperature -30°C to 80°C
Note: Mass production began in Q3 2019 and this model is currently in production. For the latest production status and detailed specifications, please contact TIANMA or their authorized distributor. The information provided is for reference only and should not be used as the sole basis for decision-making.
