BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
Specifications
connector :
51pin
signal interface :
LVDS
Supply Ability :
3000pcs per week
Package :
Original industrial packing
Model Number :
DV290FBM-N10
model :
WLED
contrast ratio :
1200:1
MOQ :
10pcs
Delivery Time :
4-5 working day
brightness :
700cd
Input voltage :
12V
Payment Terms :
T/T,W,Western Union,MoneyGram
style :
wide screen high resolution 1920*540pixels
Price :
Negotiation
material :
glass oled
Certification :
Rohs,CE,FCC
Quality :
Brand new Original
Brand Name :
BOE
color :
16.7m colors
Place of Origin :
China
working life :
50K hours
Packaging Details :
Industrial packing
Description
BOE 29-Inch Stretched LCD Display DV290FBM-N10
High-brightness 29-inch stretched LCD display with 700 cd/m² brightness and 1920×540 resolution, designed for outdoor digital signage applications.
BOE 29Inch Stretched LCD Display with 700cd/m2 Brightness 1920*540 Pixels Resolution Outdoor High Bright Digital Signage Screen
Product Overview
BOE Technology Group Co., Ltd. DV290FBM-N10 is a 29.0-inch diagonal a-Si TFT-LCD display panel featuring an integral WLED backlight system. This landscape/portrait compatible bar display offers high brightness performance with matte surface coating, making it ideal for digital signage, outdoor high-brightness applications, and stretched bar LCD implementations.
Technical Specifications
Brand BOE
Model DV290FBM-N10
Diagonal Size 29.0 inch (Native bar)
Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)×540 pixels (>3:1 aspect ratio)
Pixel Structure RGB Vertical Stripe
Active Area 705.6(H)×198.45(V) mm
Physical Size 720.8(H)×226.25(V)×21.6(D) mm
Weight 2.15±0.1 kg
Surface Coating Antiglare (Haze 25%), Hard coating (3H)
Brightness 700 cd/m² (Typical)
Contrast Ratio 1200:1 (Typical)
Response Time 15 ms (Typical, G to G)
Viewing Angle 89/89/89/89 (Typical, CR≥10)
Operating Mode HADS, Normally Black, Transmissive
Color Support 16.7M colors, 72% NTSC
Power Consumption 40.66W (Typical)
Light Source WLED, 50K hours lifespan, Without Driver
Frame Rate 60Hz
Touch Panel Without
Interface LVDS (2 ch, 8-bit), 51 pins Connector
Power Supply 12.0V (Typical)
Operating Temperature 0°C to 50°C
Storage Temperature -20°C to 60°C
Note: Production status information is for reference only. For the latest production and specification details, please contact BOE or its authorized distributors before integrating the DV290FBM-N10 into your products.
