Sharp 13.4inch 1338PPI Desktop Monitor Module LQ134R1JX45 3840×2400 500CD/M2 30PIN

LQ134R1JX45 is a 13.4" diagonal Oxide TFT-LCD display panel product from Sharp Corporation (hereafter called Sharp), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -25 ~ 60°C , and the maximal vibration level of 1.0G (9.8 m/s²). It's general features are summarized by Einklcd in the following: WLED Backlight, With LED Driver, Reverse I/F, Glossy . Based on its features, Einklcd recommend that this model be applied to Laptop etc. Now this model is in production. We inputted this model's specification on Feb 22 2022 for the first time. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with Sharp or it's agent to learn lateast production and specification detail of LQ134R1JX45. The production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.

anel Brand

Sharp

Panel Model

LQ134R1JX45

Panel Size

13.4"

Panel Type

Oxide TFT-LCD, LCM

Resolution

3840(RGB)×2400, 338PPI

Pixel Format

RGB Vertical Stripe

Display Area

288(W)×180(H) mm

Bezel Opening

-

Brightness

500 cd/m² (Typ.)

Contrast Ratio

1500:1 (Typ.) (TM)

Viewing Angle

89/89/89/89 (Typ.)(CR≥10)

Display Mode

New Mode2, Normally Black, Transmissive

Best View on

Symmetry

Response Time

30 (Typ.)(Tr+Td)

Display Colors

16.7M 100% sRGB

Lamp Type

WLED , 15K hours , With LED Driver

Frequency

-

Touch Screen

Without

Shape Style

Slim (PCBA Bent, T≤3.0mm)

Application

Signal Interface

eDP (4 Lanes) , 40 pins Connector

Input Voltage

3.3V (Typ.)

Environment

Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C
