Specifications
Brand Name :
lg
Model Number :
LC185EXN-SCA1
Certification :
Rohs,CE,FCC
Place of Origin :
korea
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
16.7M colors
model :
WLED
style :
wide screen high resolution 1366*768
brightness :
300cd
connector :
30pin
contrast ratio :
1000:1
working life :
30K hours
Description
LG 18.5" Medical Industrial LCD Panel TV - Model LC185EXN-SCA1
Product Overview

High-performance 18.5-inch LCD panel designed for demanding medical, industrial, and television applications. Features 1366*768 WXGA resolution with 300 cd/m² brightness for clear visibility in various lighting conditions.

Technical Specifications
ManufacturerLG Display
Model NameLC185EXN-SCA1
Screen Size18.5 inch
Screen TypeLCM, a-Si TFT-LCD
Resolution1366(RGB)*768 (WXGA)
Pixel ArrangementRGB Vertical Stripe
Active Area409.8 * 230.4 mm (H*V)
Outline Dimensions430.4 * 254.6 * 14.9 mm (H*V*D)
Luminance300 cd/m² (Typical)
Contrast Ratio1000:1 (Typical)
Viewing Angle89/89/89/89 (CR≥10)
Response Time9 ms (G to G, Typical)
Display TechnologyS-IPS, Normally Black, Transmissive
Color Depth16.7M colors, 68% (CIE1931)
BacklightWLED, 30K hours lifespan, With LED Driver
Refresh Rate60Hz
TouchscreenWithout
Signal TypeLVDS (1 ch, 8-bit), 30-pin Connector
Voltage Supply5.0V (Typical)
Operating Temperature0°C to 50°C
Storage Temperature-20°C to 60°C
Weight1.26 kg (Typical) / 1.35 kg (Maximum)
Surface Treatment

Antiglare coating (Haze 13%) with hard coating (3H) for durability and reduced reflections.

LG 18.5 Inch Industrial LCD Panel with 300cd/m2 Brightness and 30 Pin Connector for Medical and TV Use LG 18.5 Inch Industrial LCD Panel with 300cd/m2 Brightness and 30 Pin Connector for Medical and TV Use
Key Features
  • 300 cd/m² high brightness for industrial, medical, and TV applications
  • Original LG LCD panel in factory packaging
  • S-IPS technology for superior viewing angles and color accuracy
  • WLED backlight with 30,000-hour lifespan
  • Robust construction for demanding environments
All our LCD/LED screen monitor module panel products undergo comprehensive individual testing before shipment to ensure optimal performance and reliability.
