AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
Specifications
Brand Name :
AUO
Model Number :
G104SN03 V1
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
material :
glass oled
color :
1.07B colors
model :
WLED
style :
wide screen high resolution 800*600 PIXELS
brightness :
230cd
connector :
20PIN
contrast ratio :
500:1
working time :
30k hours
input voltage :
3.3 V
Signal type :
LVDS
Description

AUO 10.4inch lcd display G104SN03 V1 800(RGB)×600 [SVGA] 96PPI 230 cd/m² 20PIN industrial lcd display panel

Brand
AUO
Model
G104SN03 V1
Diagonal Size
10.4 inch
Type
a-Si TFT-LCD, LCM
Pixel Format
800(RGB)×600 [SVGA] 96PPI
Configuration
RGB Vertical Stripe
Active Area
211.2(H)×158.4(V) mm
Outline Dim.
236(H)×174.3(V) ×6(D) mm
Bezel Area
214.8(H)×162.0(V) mm
Treatment
Antiglare, Hard coating (3H)
Luminance
230 cd/m² (Typ.)
Contrast Ratio
500:1 (Typ.) (TM)
View Direction
-
Response Time
10/20 (Typ.)(Tr/Td)
Viewing Angle
80/80/60/80 (Typ.)(CR≥10)
Operating Mode
TN, Normally White, Transmissive
Support Color
262K/16.2M 45% NTSC
Light Source
CCFL [1 pcs] , 30K hours , W/O Driver
Weight
300g (Typ.)
Designed For
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
Frame Rate
60Hz
Touch Panel
Without
Interface Type
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply
3.3V (Typ.)
Environment
Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
AUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS InterfaceAUO 10.4inch Industrial LCD Display G104SN03 V1 with 800×600 Pixels 230cd/m² Brightness and 20PIN LVDS Interface
