Specifications
Brand Name :
auo
Model Number :
M190PW01 V8
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
brightnerss :
250CD/M2
Connector :
30P
Color :
16.7M
Contrast ratio :
1000:1
working life :
30K hours
touch panel :
without
resolution :
1440*900pixels
Description
AUO 19" 1440*900 89PPI 250cd/m² Desktop LCD Monitor M190PW01 V8
AUO 19-inch desktop monitor LCD panel M190PW01 V8 featuring 1440(RGB)*900 WXGA+ resolution, 89PPI pixel density, and 30-pin interface with 250 cd/m² brightness.
Technical Specifications
Panel BrandAUO
Panel ModelM190PW01 V8
Panel Size19.0"
Panel Typea-Si TFT-LCD, LCM
Resolution1440(RGB)*900, WXGA+, 89PPI
Pixel FormatRGB Vertical Stripe
Display Area408.24(W)*255.15(H) mm
Bezel Opening412.24(W)*259.15(H) mm
Outline Size428(W)*278(H)*10.8(D) mm
SurfaceAntiglare, Hard coating (3H)
Brightness250 cd/m² (Typ.)
Contrast Ratio1000:1 (Typ.) (TM)
Viewing Angle85/85/80/80 (Typ.)(CR≥10)
Display ModeTN, Normally White, Transmissive
Response Time3.6/1.4 (Typ.)(Tr/Td)
Display Colors16.7M 72% NTSC
Lamp Type13S4P WLED, 30K hours, Without Driver
Frequency60Hz
Touch ScreenWithout
Panel Weight1.45Kgs (Typ.)
Signal InterfaceLVDS (2 ch, 8-bit), 30 pins Connector
Input Voltage5.0V (Typ.)
Operating Temperature0 ~ 50 °C
Storage Temperature-20 ~ 60 °C
AUO 19 AUO 19
Product Overview
The M190PW01 V8 (Alias: M190PW01 V.8) is a 19.0-inch diagonal a-Si TFT-LCD display panel from AU Optronics Corp. featuring an integral WLED backlight system without backlight driver or touch screen. This panel operates within a temperature range of 0~50°C and stores safely at -20~60°C.
Key features include WLED backlight, upside interface, matte surface finish, and TCO 5.1 compliance (PART NO.: 97.19M09.800). This model is recommended for desktop monitor applications.
According to production records, this model entered mass production in Q1 2011 with final shipments in Q1 2019. The M190PW01 V8 is now discontinued. Specification data was first recorded on April 10, 2013, with the latest update on August 6, 2019.
For integration of M190PW01 V8 LCM into future products, we strongly recommend contacting AUO or their authorized agents for the latest production and specification details. The production status information provided is for reference only and should not be used as the sole basis for decision-making.
