AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
Specifications
Brand Name :
AUO
Model Number :
M270DTN01.3
Certification :
CE,FCC,ROSH,UL,REACH
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
Western Union,MoneyGram,T/T
Supply Ability :
20000pcs per week
Delivery Time :
3-4 days
Packaging Details :
industrial package
Material :
glass
size :
27inch
constraction :
1000:1
Pixels :
2560*1440
contactor :
130pin
working life :
30k hours
Display colors :
16.7M
Weight :
2.39kg
Description
M270DTN01.3 27" Quad-HD LCD Display Panel
2560*1440 resolution, 130-pin AUO 27" laptop LCD screen with 350 cd/m² brightness
Panel Specifications
Specification Details
Panel Brand AUO
Panel Size 27.0"
Resolution 2560(RGB)*1440 (Quad-HD, 108 PPI)
Display Area 596.736(W)*335.664(H) mm
Outline Size 608.8(W)*354.66(H)*15.08(D) mm
Brightness 350 cd/m² (Typical)
Viewing Angle 85/85/80/80 (Typical, CR≥10)
Display Colors 16.7M, 98% sRGB
Refresh Rate 144Hz
Weight 2.39 kg (Typical)
Technical Details
Parameter Specification
Panel Model M270DTN01.3
Panel Type a-Si TFT-LCD, LCM
Pixel Format RGB Vertical Stripe
Surface Treatment Antiglare, Hard coating (3H)
Contrast Ratio 1000:1 (Typical)
Display Mode TN, Normally White, Transmissive
Response Time 3.5/1.5 (Typical)(Tr/Td)
Backlight System 18S4P WLED, 30K hours, Without Driver
Touch Screen Without
Interface & Environmental Specifications
Signal Interface LVDS (8 ch, 8-bit), 130 pins Connector
Input Voltage 12.0V (Typical)
Operating Temperature 0 ~ 50 °C
Storage Temperature -20 ~ 60 °C
AUO 27-inch Desktop Monitor Gaming LCD
M270DTN01.3 features 2560*1440 pixels, 108 PPI, 130-pin connector, 350 cd/m² brightness - original brand new
AUO M270DTN01.3 27 Inch LCD Display Panel with 2560x1440 Pixels 350 cd/m² Brightness and 130 Pin Connector
Product Overview
AU Optronics Corp. M270DTN01.3 is a 27.0-inch diagonal a-Si TFT-LCD display panel with integrated WLED backlight system. This panel operates within 0~50°C temperature range and withstands vibrations up to 1.5G (14.7 m/s²).
Key Features
  • sRGB color gamut coverage
  • 3-side borderless design
  • 144Hz refresh rate for smooth gaming
  • 3D display capability
  • WLED backlight technology
  • Matte anti-glare surface
  • G-Sync compatibility
  • TCO 6.0 compliance
Recommended Applications
Ideal for desktop monitors and gaming applications where high refresh rates and Quad-HD resolution are essential.
Production Status: Mass production began Q4 2014. Current production status should be verified directly with AUO or authorized distributors for the latest specifications and availability.
