Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy
Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy
Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy
Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy
Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy
Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy
Specifications
Brand Name :
Shenghe
Model Number :
Silicone Coated Fiberglass Sleeving
Certification :
ROSH
Place of Origin :
China
MOQ :
100 Meters
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
50000Meters/Day
Delivery Time :
5-7 Work days
Packaging Details :
Roll
Product Name :
fiberglass rope seal
Roll Length :
20 Meters
Performance :
Fire-proof and High Temperature
Raw Material :
9um E-glass,red Silicone Rubber
Working Temperature :
-65 Degree C To 500 Degree C
Breakdown Voltage :
10 kV to 15 kV
Application :
Used to Protect Hoses, Wires And Cables
Flammability :
Pipe Protection
Description

Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy

Description for High-Temperature Silicone Rubber Fiberglass Sleeving

Silicone-coated fiberglass sleeves withstand repeated exposure to molten steel, aluminum, and glass up to 3000°F. These specially designed compounds instantly shed a splash of molten metal, so little heat transfer occurs. These Sleeves are rough-textured, woven from non-combustible knitted E-type fiberglass yarns with 5mm rhombus air gaps at every 3mm distance, providing self-cooling in a flexible substrate, and are covered with a thick layer of red silicone rubber that provides a high level of thermal insulation and fire protection. When exposed to flames, the silicone rubber becomes an outer shell, forming a protective SiO2 refractory layer that effectively prevents burns from hot hoses and flexible steam lines while reducing heat loss.

Operation Temperature

Continuous Operating Temperature: -65 ° C - 260 ° C

15-20 minutes: 1090 ° C

15-30 seconds: 1650 ° C

Technique Data

Description: Texturized fiberglass sleeve with silicone coating
Contents: 100% glass fiber and silicone rubber
Yarn type: 9 um
Internal Diameter : 30mm
Thermal Conductivity 0.035(w/(m.k)
Continuous Temp resistance: No more than 550 0C
Freeze temp: -50 0C
Loss on Ignition ≦3.52%
Chemical composition
SiO2 Al2O3 CaO MgO R2O Fe2O3
67.3±0.5 % 6.4±0.4% 9.6±0.3% 4.5±0.3 % 11.8~16.1% ≤0.4

Features:

Superior Electrical Properties.

Good Expandability and Flexibility.

Chemical Resistance.

Extreme Abrasion Resistance.

Oil Resistance.

Self Extinguishable.

Application:

Mainly used in steel plants, smelters, glass, and other thermal places to protect the hose, hose assemblies, and cables. It also helps maintain line temperature and reduce environmental overheating and overcooling.

Transportation (Aerospace, Auto, Locomotive, Heavy Equipment)

Generally used in electrical and electronic wiring, lighting, industrial machinery, electric products, and other places of high temperature

Durable Silicone Rubber Fiberglass Sleeving Flame Retardancy

The Other Types Recommended:

Dia (mm) Internal Dia (mm) Length (m) Thickness(mm)
Silicone Glass Yarn
1 6 6.5 20 0.6 1.0
2 8 8.5 20 0.8 1.0
3 10 10.5 20 0.8 1.0
4 12 12.5 20 0.8 1.2
5 15 15.5 20 0.9 1.2
6 20 20.5 20 0.9 1.4
7 22 22.5 20 0.9 1.4
8 25 25.5 20 1 1.6
9 30 30.5 20 1.1 1.8
10 32 32.5 20 1.2 1.8
11 35 35.5 20 1.1 2
12 40 40.5 20 1.2 2.1
13 45 45.5 20 1.2 2.2
14 50 51 20 1.2 2.3
15 55 56 20 1.3 2.4
16 60 61 20 1.3 2.5
17 65 66 20 1.3 2.6
18 70 71 20 1.4 2.7
