Specifications
Brand Name :
BaiHang
Certification :
CE
Place of Origin :
Qingdao ,China
Supply Ability :
3000sets /year
Place of origin :
Qingdao ,China
Cabinet :
Furniture, doors and cabinets Industry
Price :
$2000 - $2400
Delivery Time :
8-20Days
Packaging Details :
3310*2250*1030mm
Key selling points :
Easy to Operate,High-accuracy
Keywords :
CNC Wood MDF Furniture Carving CNC Router
Model Number :
BH1325M
Payment Terms :
T/T
Brand name :
BH
MOQ :
1
Application :
Kitchen Cabinet Doors Furnitures Making
Product name :
High Accuracy Woodworking CNC Router Machine for Plywood MDF
Description
High Accuracy Woodworking CNC Router Machine for Plywood MDF
High Accuracy Woodworking CNC Router Machine for Plywood MDF
Product Overview
Engineered to offer consistent dependable operation, our CNC router adopts a sturdy build paired with a stable, high-accuracy control unit for seamless coordination. As a professional PC-controlled solution, it balances strong cutting power and precise machining, standing out for its great value and supported by premium after-sales support.
Technical Specifications
Component Specification
Fuselage structure Square tube welded bed body, detachable
Longmen structure Thickened square steel gantry, cast iron columns
Mesa structure Aluminum profiles+PVC, vertical laying of profiles
Body size 3100*2000*1750mm
Table size 1300*2500mm
Effective work schedule 1.3mX2.5m (standard board size)
Machining accuracy 0.05mm
Transmission structure Three axis 20 square track and slider
Rack 1.25m high-precision gear rack
Z-axis component Drive belt+gear transmission
Motor set Chuangwei 450B stepper motor
Driver Skyworth 860 Drive
Spindle power 6.0KW air-cooled spindle, speed 24000 RPM
Frequency converter Zhuzhou 7.5KW frequency converter
Operating system JM Weihong
Cabinet Independent chassis control cabinet
Machine color Grayish green
Working voltage 380/220V 50Hz
Special Note: Customers are allowed to customize machine models and configurations as required. Since we supply many different products, prepayment is needed to confirm orders. Quotations will be offered depending on your actual demands. Please check the real price with our sales staff after confirming the model and configuration. Get in touch with us to learn more about our products!
Key Features
MACHINE PARTS
Brand: BH
Origin: China
Features: long lifespan, low noise, free maintenance
High Accuracy Woodworking CNC Router Machine for Plywood MDF
MAIN FEATURES
Three-axis 20 square rail and slider
Brand: BH
Origin: China
Features: fast running speed and strong bearing capacity
High Accuracy Woodworking CNC Router Machine for Plywood MDF
MACHINE PARTS
Name: T-slot Table
Brand: BH
Origin: China
Features: much more economic
High Accuracy Woodworking CNC Router Machine for Plywood MDF
MAIN FEATURES
Origin: China
Name: independent control cabinet
Features: easy to operate and simple to control
High Accuracy Woodworking CNC Router Machine for Plywood MDF
Optimized Technical Specifications
  • Aluminum profile worktable with PVC surface: The extended aluminum beam structure delivers strong load-bearing performance, while the PVC protective layer safeguards the aluminum profile base from abrasion.

    Stepper motor assembly: Premium spindle unit and cutting head support prolonged continuous running, lowering component wear, enabling rapid bearing rotation and quieter operation.

    Heat-treated square steel gantry: Constructed from 1cm thick heat-treated square steel, the gantry provides outstanding structural rigidity, stable running motion and superior machining precision.

    Cable drag chain: Updated wear-resistant drag chain separates power cables and signal lines to avoid signal interference and prevent cable twisting during machine operation.
Applications
Core Applications:
  • Woodworking: Panel fabrication, door and window production, furniture engraving and customized woodwork processing.

    Advertising industry: Sign manufacturing, logo cutting and acrylic display product machining.

    Model and prototype making: Architectural scale models, wooden patterns, foam molds and stage prop fabrication.

    Art & handicraft production: Musical instrument carving, decorative engraving and custom craft gift manufacturing.
Frequently Asked Questions
Q1: Do you accept custom orders?

A1: Yes. We can customize machine color, dimensions and logo as requested.

Q2: Where is your factory?

A2: We are a manufacturer located in Qingdao, Shandong Province, China.

Q3: Can you manufacture machines based on my drawings or samples?

A3: Sure. Our professional designers will work out suitable design and production plans for you.

Q4: This is my first CNC machine. Is it easy to operate?

A4: We provide English operation manuals and teaching videos. Free professional guidance will be offered until you can operate it skillfully.

Q5: What is MOQ and delivery method?

A5: MOQ is 1 set. We ship goods directly to your local port. Send us your port name to get precise price and shipping cost.

Q6: How about your after-sales support?

A6: Our team offers 24-hour online service. Overseas installation service is available as well.

Q7: Can you repair my machine if it malfunctions?

A7: Yes. Free online training is provided. We offer repair service for breakdowns within the warranty term.
