Digital Flexo Plate Machine FL-800 For Label Printing
Digital Flexo Plate Machine FL-800 For Label Printing
Specifications
Brand Name :
EcooGraphix
Model Number :
EcooSetter FL-800
Certification :
CE
Place of Origin :
China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
1000 sets/year
Delivery Time :
35 days
Packaging Details :
Standard Exporting Package
Classification :
CTP Plate Machine
Product Name :
Digital Flexo Plate Making Machine
Laser Channel :
16/32CH
Output Speed :
1.25/2.5 M2/H
Max. Breadth :
790mm x 690mm
790mm x 690mm :
0.14mm-2.84mm
Laser Power :
High power semiconductor laser diode
Application :
Label and trademark
Resolutions :
4000dpi
Power :
220V/50Hz, 60Hz, mainframe 1.5KW+Vacuum 2.0KW
Plate Thickness :
0.14mm - 1.7mm
Interface :
USB2.0
Focus Adjust :
Fixed focus
Description
Digital Flexo Plate Machine FL-800 For Label Printing
Flexo CTP Machine Digital Flexo Plate Making Machine

Model: EcooSetter FL-800

Digital Flexo Plate Machine FL-800 For Label Printing
Specification

Model FL-800E FL-800S
Laser Channel 16-channel 32-channel
Output Speed 1.25m²/h 2.5m²/h
Max. Breadth 790mm x 690mm 790mm x 690mm
Plate Thickness 0.14mm - 2.84mm
Laser Power High power semiconductor laser diode
Plate Type Digital relief flexo plate(water-wash), Digital flexo plate (water-wash), Digital flexo plate (solvent-wash) Steel based digital plates (Water/alcohol washable)
Application Label and trademark
Resolutions 4000dpi
Plate Loading Manual load and unload
Interface USB2.0
Focus adjust Dynamic auto-focus
Device Size 1610x910x980mm(WxDxH) 1610x910x980mm(WxDxH)
Net Weight 800Kg 800Kg
Power 220V/50Hz, 60Hz, mainframe 1.5KW+Vacuum 2.0KW
Environment Recommended temperature: 15-30℃ Humidity: 40%-70%
Features

1. Drum Auto Balance
The Drum Auto Balance system maintains printing drum stability during high-speed operations by automatically adjusting a balance block within the drum assembly.
How it works:
In label printing, the drum applies toner or ink onto the substrate. The system ensures any imbalance in rotation is corrected within 5 seconds by adjusting the balance block position.
Benefits:
  • Stability at High Speeds: Maintains smooth operation during rapid printing tasks
  • Reduced Downtime: Minimizes wear and tear, maximizing production efficiency
  • Better Print Quality: Ensures even application of toner for high-quality, uniform prints
2. Auto Switch of Laser Channel
This fail-safe system detects malfunctioning laser channels and automatically switches to available functional channels.
How it works:
If a laser channel fails, the system reroutes the process to the next working channel, allowing continuous production without interruption.
Benefits:
  • Non-stop Production: Continues working despite laser channel malfunctions
  • Minimized Downtime: Allows scheduled maintenance without affecting operations
  • Increased Reliability: Provides redundancy for continuous output
3. Linear Motor
Replaces traditional rotary motors with linear motors for high-precision printing tasks.
How it works:
Uses electromagnetic force to produce straight-line motion, providing precise control over printer component movement.
Benefits:
  • Increased Precision: Enables highly accurate movement for sharp images
  • Simpler Design: Fewer moving parts reduce mechanical complexity
  • Higher Reliability: Longer operational lifespan with less wear
  • Faster Response: Quick adjustments ideal for fast-paced production
4. Dynamic Autofocus
Maintains precise laser focus throughout the printing process as conditions change.
How it works:
Continually adjusts focus based on printing head position and substrate, ensuring perfect focus at all times.
Benefits:
  • Consistent Print Quality: Maintains sharp prints during high-speed runs
  • Adaptability: Compensates for material shifts during printing
  • Reduced Manual Calibration: Saves time and increases efficiency
Digital Flexo Plate Machine FL-800 For Label Printing Digital Flexo Plate Machine FL-800 For Label Printing
FAQ

1. Q: What are your main products?
A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, Flexo CTP, Processor, Offset Plates, inks, blankets, postpress packing equipments and so on. There are over 3000sets CTPs installed worldwide. Our partners in USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa and so on are very pleased with our technician support service and product performance. We also have five offset plates production lines producing the thermal CTP plate(single and double layers), positive CTCP plates(single and double layers) and Chemistry free CTP plate. You can get the prepress equipments and consumables all in one and no worry about the after-sales service from our company.
2. Q: Where is your factory?
A: Our CTP machine factory is located in Hangzhou city, which is about 1.5 hour by train from Shanghai. You are warmly welcomed to visit our factory!
3. Q: What is your warranty for the CTPs?
A: One years' Laser Head and main spare parts for the CTP.
4. Q: What is the Lead Time?
A: Usually 30 days, and we will try our best to meet your demands.
5. Q: Can you also supply the Workflow and RIP?
A: Yes, we can provide the Workflow Brain New and RIP Compose V9.
6. Q: What about the Installation and after-sales technician support?
A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
