0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
0.30mm Processless Thermal CTP Plate – Aluminum DOP for Offset Printing
Specifications
Brand Name :
EcooGraphix
Model Number :
ECOO-G
Certification :
ISO9000, CE
Place of Origin :
China
MOQ :
1000 Square Meters
Payment Terms :
L/C,T/T
Supply Ability :
300,000 Sqm/Year
Delivery Time :
30 Days
Packaging Details :
Standard Export Packing
Price :
Negotiable
Plate Type :
CTP Plate
Low-energy imaging :
130-150 Mj/Square Centimeter
Run Length :
100, 000 Impressions
Thickness :
0.15mm/ 0.30mm
Maximum short grain width :
Maximum Width 1280 mm
Processing :
Without Processing, Directly on Press
Platesetter :
Kodak Screen Thermal Platesetters EcooSetter
Coating Color :
Grey
Packing :
50pcs/carton
Description

Application


The EcooGraphix ECOO-G is an innovative, eco-friendly Development On Press (DOP) CTP plate. After imaging, it can be placed directly on the printing press, eliminating the need for chemical processing.

Recommended press procedure for ECOO-G:

  1. Thoroughly clean ink residues from the blanket.

  2. Start the press and engage the water roller for 30–40 seconds.

  3. Activate the ink rollers for 20–30 seconds.

  4. Feed paper and begin printing.

Note: Extending steps 2 and 3 helps reduce paper waste.


Specification


Model ECOO-G
Plate Type Thermal-negative type
Application High-grade commercial and newspaper printing
Substrate Electrolyte graining and Anodized AL substrate
Thickness 0.15mm/ 0.30mm
Maximum short grain width Maximum width 1280 mm
Spectrum scope 800-850 nm
Photosensitive wavelength 830 nm
Platesetter Various dominant thermal platesetters in the market
Coating color Grey
Low-energy imaging 130-150 MJ/cm²
The period of latent image stabilization ≤ 7 days
Recommended screen method 1-99% @200 LPI AM or 20μm FM or mixture
The paper number of start-up < 50 sheets
Safety light 4 hours under yellow light; 1 hour under fluorescent lamp;
Direct exposure under natural light is safe but not recommended.
Processing Without processing, directly on the press
Run Length 100,000 impressions;
Actual run length depends on printing conditions
Shelf life 12 months under recommended condition
Transportation Packed in seal and stored using prevention
from light, moisture, overheating, and high humidity
Storage Recommended condition: 18ºC-24ºC, 40%-50% RH.

​


Applied parameters in the Imaging device

​

CTP model
Data		 Kodak
trendsetters		 LOTTEM 400(TH1.7) MAGNUS 400 Screen 8600S
Laser power 15-17W 300-320mw 19.5-21.5W 80-90 %
Drum speed 250-300rpm 850-900rpm 400-450rpm 800-900rpm
Resolution Customized Customized Customized Customized
Parameter that needs set up Focus/ Zoom Focus/ Zoom Focus/ Zoom Focus/ Zoom


*Note: Higher exposure energy will make the image contrast clear and benefit the plate run length.

while over-high/low exposure energy will affect the image quality negatively.

ECOO-G Processless CTP plate Video: https://youtu.be/LLqNaY1ivcI
​


Characteristics

The ECOO-G plate features a double-layer structure:

  • The emulsion layer is non-water-soluble, ensuring it does not mix with the fountain solution.

  • The protective layer is water-soluble and dissolves quickly into the fountain solution, enabling smooth press performance.
