All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
Specifications
Brand Name :
EcooGraphix
Model Number :
ECOO ZBS 320
Certification :
ISO9000, CE
Place of Origin :
China
MOQ :
1 SET
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500 Sets/Year
Delivery Time :
30 DAYS
Packaging Details :
Standard Export Packing
Machine Type :
Label Printing Machine
Model :
Ecoo Label IQ-330
Max. roll diameter :
350mm
Max. media width :
330mm
Max. Unwinding Diameter :
600mm
Max. Rewinding Diameter :
600mm
Description
Product Description
All-in-One Digital Label Printing, Foiling & Die Cutting Machine
Product Description
  1. Integrated Versatility: One machine, infinite possibilities. The Ecoo Label IQ-330 combines printing, laminating, cutting, and slitting into a single device, simplifying your production line and enhancing overall efficiency.
  2. Excellent Printing Performance: Whether using white, varnish, or colored UV inks, the Ecoo Label IQ-330 delivers outstanding print quality on a wide range of media, helping your labels stand out on the shelf.
  3. High precision cutting: Featuring ball screws and independent servo motors, the machine achieves a cutting accuracy of ±0.1mm, ensuring flawless labels every time.
  4. Wide Range of Applications: From food packaging and cosmetic labels to electronic product identification and industrial data encoding, the Ecoo Label IQ-330 handles it all with ease.
Digital Label Printing Machine
Model Ecoo Label IQ-330
Max. roll diameter 350mm
Max. media width 330mm
Print head EP i3200-U1x4
Ink Type UV ink
Ink color CMYK+W+V
Ink bottle capacity 1L
Print speed 4pass:56m/h 6pass:40m/h 8pass:28m/h
File format JPG/ PNG/ PDF
Cutting length 10-350mm
Cutting width 10-320mm
Repeat die-cutting accuracy 0.1mm
Number of die-cutting heads 2
Number of slitting knives Standard 3 (optional according to requirements)
Power consumption 4kW
Power supply AC220-240V, 50-60hz
Weight 2000KGS
Printer size 2500mm*1800mm*1700mm
Laminating specification Wide 330mm
Gold foil standard Hot foil stamping
Printing resolution 720*1200 720*1800 720*2400
Max. Printing width 330*320mm
Min. Printing width 330*100mm
Max. Printing length 10000mm
Min. Printing length 0.5mm
Thickness of printing materials Less than 300g
Technical data
Description Brand Quantity Origin
Printing roller
3sets China
Anilox roller Auclean/Laser 1set China
Unwind tension controller Mitsubishi 1set Japan
Rewind tension controller ZXTEC 1set China
Main motor Wannan 1set china
Transducer Mitsubishi 2sets Japan
Magnetic power brake/clutch Ningxia 3sets China
Electromagnetic valve Airtac 2 set Taiwan
Inverter Schneider 1set Frence
AC Contactor Schneider 2pcs France
Time relay C-LIN 1pc China
Solid relay Omron 6pcs Japan
Micro relay Weidmiiller 2pcs Germany
Temperature Controller Yuyao 6pcs China
Air switches fromSiemens 8pcs Germany
Low-pressure wiring Schneider All France
All the bearing NSK/CHINA
JAPAN/CHINA
All-in-One Digital Label Printing, Foiling and Die Cutting Machine
All-in-One Digital Label Printing, Foiling and Die Cutting Machine All-in-One Digital Label Printing, Foiling and Die Cutting Machine All-in-One Digital Label Printing, Foiling and Die Cutting Machine All-in-One Digital Label Printing, Foiling and Die Cutting Machine
