ECOO-FILM
ECOO-FILM
Specifications
Place of Origin :
China
Brand Name :
EcooGraphix
Delivery Time :
30 Days
Payment Terms :
T/T
Description
Model ECOO-FILM
Plate Type Alliance far red film
Spectral Sensitivity HeNe laser and red laser diode (630-670nm)
Description Emulsion coated on a 0.10 mm antistatic polyester base
Practical Photographic Properties with Different Engine
Engine Accuset Avantra
Int. Setting 170 230
Practical Density D.4.00-4.20 D.4.10-4.30
5% 5% 5%
50% 57% 53%
95% 98% 96%
Processing time 20-40 sec
Processing temperature ​35ºC or 95ºF
Developer Replenishment
(eg, ACD/ASD)		 15% exposure 50ml/m²
50% exposure 150ml/m²
85% exposure 250ml/m²
Anti-OX replenishment 1000 ml/24h= 0.264 US gallons/24h
Fixing temperature 32ºC or 90ºF
Fixer replenishment(Without Fixer electrolysis) 15% exposure 500 ml/m²
50% exposure 300ml/m²
85% exposure 100ml/m²
Fixer replenishment with Fixer electrolysis 125 ml/m²
Practical set-up density D 4.00-D.4.20 (dot gain depending on the optical quality of the imagesetter)
Chemical Compatibility Processable in all rapid access chemistries and in main hard dot chemistries such as RA2000, Fuji HQ QRD-1 AND QRD-1P
Dimensional Stability Humidity coef: 0.10mm base, Crh 0.016mm/m/%RH
Temp. coef: 0.10mm base, Cot 0.018mm/m/1ºC
Safe light Dark Green recommended: encapsulate T20/ND.75 or equivalent
Storage The films are preferably stored in a cool dry place temperature below 20ºC and relative humidity between 30% and 60%
