Specifications
Place of Origin :
China
Brand Name :
DUHM
Model Number :
WBC-105.0H-A-S
Price :
Negotiable
MOQ :
2
Packaging Details :
Polywood Pallet
Delivery Time :
25-30 working days
Payment Terms :
T/T,L/C AT SIGHT
Supply Ability :
800 SETS/DAY
After-sales Service Provided :
Free spare parts
Warranty :
1 Year
Operating Language :
English
Application :
Garage, Household
Power Source :
Electric
App-Controlled :
NO
logo/pattern :
Silk screen printing, Laser Printing
Type :
Air Source Heat Pump
Installation :
Freestanding
Storage / Tankless :
Instant / Tankless
Housing Material :
Metal, Galvanized Steel with Powder coated
Use :
Bathroom
Product Name :
R410A Hot Water Heater
Refrigerant :
R410A
Heating Source :
Air to Water Heat Pump
Function :
Commercial Hot Water
Heating Capacity(A20/15℃,W 15/55℃) :
66.38 kW
Compressor :
Rotary
Power Supply :
380~415V/3/50Hz/
Operating Ambient Temperature :
-10°C~45°C
Water Flow Volume :
11.41 m³/h
Description

Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM

Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Model
WBC-70.0H-B-S
WBC-105.0H-A-S
WBC-180.0H-A-S
Heating Condition 1-Ambient Temp. (DB/WB): 20/15℃, Water Temp. (In/Out): 15/55℃
Heating capacity
kW
66.38
88.50
177.00
COP
W/W
3.83
3.85
3.85
Power input
kW
17.33
22.99
45.97
Current input
A
31.00
41.12
82.24
Heating Condition 2-Ambient Temp. (DB/WB): 7/6℃, Water Temp. (In/Out): 9/55℃
Heating capacity
kW
54.41
72.54
145.08
COP
W/W
3.22
3.20
3.23
Power input
kW
16.90
22.67
44.92
Current input
A
30.23
40.55
80.35
Max power input
kW
26.00
34.48
68.96
Max current input
A
46.5
61.7
123.4
Power supply
V~Hz
380V 3N~ 50Hz
Operating ambient temperature
°C
-10°C~45°C
Water Flow Volume
m³/h
11.41
15.22
30.44
Water Pressure Drop
kPa
50
50
60
Outlet Water Temp.
°C
55
Max.Outlet Water Temp.
°C
60
Water Connection
inch
DN65
DN65
DN80
Water pump
qty
0
0
0
Compressor
qty
1
1
2
Fan motor
qty
1
1
2
Noise
dB(A)
66
66
69
Net dimension
L / W / H
mm
1100*1100*1770
1100*1100*1770
1100*2290*1770
Package dimension
L / W / H
mm
1120*1120*1890
1120*1120*1890
1120*2310*1890
Net weight
kg
585
635
1143
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
Public Places R410A Air Source Hot Water Heat Pump with Customized Function by DUHM
