Specifications
Model Number :
UL3662
Payment Terms :
T/T, L/C
Voltage :
4200V
Condutor :
Bare copper or tinned copper
Place of Origin :
China
Packaging Details :
in roll or splint reel
MOQ :
100meter
Delivery Time :
within 10days
Price :
USD0.302 to USD6.265/m
Temperature :
-60-+180℃
Certification :
UL
Supply Ability :
10000km per week
Color :
Black/red/....
Brand Name :
ECHU
Description

UL758 Standards UL3662 Flexible EV Silicone Rubber Cable High Heat Resistance Single Conductor Sr Cable

UL3662 Single-Conductor Silicone Rubber AWM Cable UL3662 is a high-temperature, high-voltage silicone rubber wire complying with UL758 Appliance Wiring Material standard.

  • Construction Conductor: Class 5 flexible stranded bare or tinned copper; Insulation: Extruded silicone rubber.
  • Electrical & Thermal Ratings Rated Voltage: 4200V Operating Temperature: -60°C ~ +180°C (dry locations)
  • Flame Performance Self-extinguishing, meets UL FT2 horizontal flame test.
  • Key Features Excellent flexibility, outstanding heat resistance, low-temperature resistance, ozone resistance, UV resistance and chemical resistance. High dielectric strength suitable for high-voltage circuits; halogen-free, RoHS compliant.
  • Typical Applications Internal wiring for high-temperature & high-voltage equipment, industrial machinery, heating devices, new energy equipment, motor connection and oven appliances.
Item UL3662 Silicone rubber cables
Conductor Bare copper
Insulation Silicone Rubber
Rated Voltage 4200V
Temperature Range Maximum Working Temperature: -60ºC to +180ºC
Color Optional
Application

UL/CSA approved, temperature resistant silicone single core for the internal wiring of switch cabinets, electrical and electronic devices; for use in iron, steel and rolling mills, foundries, and cement, glass and ceramic factories.
