5-Port 10 / 100 / 1000M Switch with 4-Port POE power up to 66W for all PoE ports
5-Port 10 / 100 / 1000M Switch with 4-Port POE power up to 66W for all PoE ports
Specifications
Place of Origin :
ShenZhen China
Brand Name :
Fiberroad
Model Number :
FR-POE3505G-XX
Certification :
CE , ISO9000 , SGS , FCC , LVD
Description

5-Port 10/100/1000M Switch with 4-Port POE

The 5-Ports Gigabit PoE switch is an unmanaged 10/100/1000Mbps Gigabit Ethernet PoE switch designed to enhance workgroup performance while providing a high level of flexibility. It provides 5 x 10/100/1000Mbps ports and 4 IEEE802.3af Power over Ethernet (PoE) ports for workstation. It is an ideal solution for small office and home users to utilize a combination of Gigabit PoE and non-PoE device. The switch automatically detects IEEE 802.3af compliant devices and provides power and data over a single cable.

Key Features

  • 5 x 10/100/1000Mbps Auto-negotiation Fast Ethernet RJ-45 ports with 4-Ports PoE function ( port 1 ~ port 4)
  • Compliant with IEEE 802.3af
  • Supports PoE power up to 66W (af) for all PoE ports.
  • Supports PoE IEEE802.3af compliant Powered Device (PD)
  • Each port supports auto MDI/MDIX, so there is no need to use cross-over cables.
  • Full/half duplex transfer mode for each port.
  • Wire speed reception and transmission.
  • Up to 2K unicast address entities per device. Self-learning, and table aging.
  • 9216-byte jumbo packet length.

Specification

StandardIEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet (twisted-pair copper)
ProtocolCSMA/CD
Data Transfer RateEthernet: 10Mbps (half-duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex)
Gigabit Ethernet: 2000Mbps (full duplex)
Network Cables10Base-T: 2-pair UTP Cat 3, 4, 5 up to 100 meters.
100Base-T : 2-pair UTP Cat 5, 5e up to 100 meters.
1000Base-T: 4-pair UTP Cat5e 6, up to 100meters.
Number of Ports5 x 10/100/1000Mbps auto-MDIX RJ-45 ports with 4 PoE enabled ports.
PoE power on RJ-45Power +: pin 3 & pin 6 ; Power –: pin 1 & pin 2
AC to DC power supplyInput: 100V ~ 240VAC, 50Hz ~ 60Hz. Output: 48VDC 1.5A

Power Consumption6.0 watts ( max with no PD device connected)
66watts ( 4 PoE ports 15.4W/port)
TemperatureOperation: 0℃~ 40℃or 32℉~ 104℉
Storage Temperature: -10℃~ 70℃or 14℉~ 158℉
HumidityRelative Humidity: 5% - 95%
Dimensions151 mm W x 126 mm D x 36 mm H
EMIFCC Class B, CE Mark Class B
Safety100VAC to 240VAC power supply UL listed.
Filtering Address Table2K entries per device
Packet Filtering Forwarding Rate

10Mbps Ethernet: 14,880/pps

100Mbps Ethernet: 148,800/pps

1000MBase-T Ethernet: 1,488,000/pps.

MAC address LearningAutomatic update
Transmission MethodStore–and–Forward

Ordering information

P/NDescription-XX
FR-POE3505G-XX

5-Port 10/100/1000M Switch with 4-Port POE

T:IEEE802.3at

F:IEEE802.3af

N:Non－standard

1：15.4W

3: 30W
