Double Shear Beam Load Cell, Micro Sensor, Transducer, Transmitter, Capacity: 2t, 5t, 10t
Double Shear Beam Load Cell, Micro Sensor, Transducer, Transmitter, Capacity: 2t, 5t, 10t
Specifications
Place of Origin :
CHINA
Brand Name :
LIGENT
Model Number :
LF-51D
Description

Features and Applications:

Bridge, alloy steel load cell.
Suitable for cold & hot press machines, construction machinery, hopper scales, and platform scales, etc.

Technical Specification Sheet
Capacity2t, 5t, 10t
Rated Output2.0 ± 10% mV/VMaterialAlloy Steel
Zero Balance± 2%F.S.Insulation≥5000MΩ/100VDC
Non-linearity0.03 % F.S.Recommended Excitation10V
Hysteresis0.03 % F.S.Maximum Excitation15V
Repeatability0.03 % F.S.Compensated Temp Range－10 ~ 60℃
Creep(30min)0.05% F.S.Operating Temp Range－20 ~ 80℃
Temp Effect on Output0.05 % F.S. / 10ºCSafe Load Limit120%
Temp Effect on Zero0.05 % F.S. / 10ºCUltimate Load Limit150%
Input Impedance385 ± 10 ΩCable SizeΦ5 × 3m
Output Impedance350 ± 5 Ω　　
Wire ConnectionEx＋ : Red; Ex－ : Black; Sig＋ : Green; Sig－ : White
