Specifications
Place of Origin :
China
Brand Name :
MSHOT
Model Number :
MF-BG-LED
Certification :
ISO,CE,FCC
Description

LED Fluorescence Illumination MF-LED Series

MF-LED series LED fluorescence illumination features with built-in color LEDs as light source. Providing user friendly fluorescent microscope upgrade solution for microscope end users. By the modular fluorescent illumination you can easily upgrade a ttraditional infinity upright biological microscope to fluorescence functional. Its super optical compatibility support different popular laboratory microscopes such as Olympus, Nikon, Leica and Zeiss.

WHO pointed LED fluorescence microscope as the most suitable microscope for quick TB diagnostic in the year of 2010. It makes fluorescence illumination in LED light source widely used in clinical application especially for immunofluorescence (IFA). The high-efficiency , modular and energy-saving LED attachment can make a basic simple microscope to a high efficiency epi fluorescence microscope with easy operating and long working life.

Matched microscopes

  • Olympus CX22, CX23, CX31,CX41,BX43,etc
  • Nikon E100, E200,etc
  • Leica DM500, DM700
  • Zeiss PrimoStar

MF-LED Series LED fluorescence illumination advantages:

  • Instant available, no need of warm up and cooling.
  • No need of district dark room surrounding.
  • High efficiency LED light excitation to provide brighter fluorescent.
  • Long life time LED lamp, no need to replace lamp, more cost effective than mercury lamp.
  • Immediatly mount to microscope, users does not need have experienced microscope installation skill.

Recommend Fluorescein Application

Mode

Excitation filter wavelength

Suitable Fluorescein

MF-RB-LED

420-480nm

Special for TB Diagnostic

MF-B-LED

460-490nm

GFP / FITC /EGFP/ Malaria diagnostic/ Alexa 488 / Cy2@ / Fluo-4 / FluorX@ / Fluoro-Jade

MF-G-LED

510-550nm

PI / EB / EH

MF-UV-LED

330-380nm

DAPI / Hoechst 33342&33258 / AMCA/AMCA-X / Alexa 350

Parameters :

Data Sheet of MF-LED fluorescence illumination
Mode LED lighting central wavelength Excitation filter wavelength Dichroic mirror wavelength Emission filter wavelength
MF-B-LED (Blue) 475nm 460-490nm >500nm >510nm
MF-RB-LED (Royal blue) 450nm 420-480nm >500nm >510nm
MF-G-LED (Green) 530nm 510-550nm >570nm >590nm
MF-UV-LED (UV) 365nm 330-380nm >400nm >420nm
MF-V-LED (Violet) 405nm 395-415nm >420nm >440nm

With clients specific requirement, fluorescent filters in Chroma, Semrock,Omega are optional

Fluorescence illumination for epi fluorescentFluorescence illumination for epi fluorescentFluorescence illumination for epi fluorescent
