Specifications
Place of Origin :
China
Description

Model:China ATV500CC02

Approve mode:EEC EPA DOT
Product description:
(1)Product Type:500ATV or tracked vehicle
(2)Engine Mode:SQ500ST-2
(3)Overall dimension:(L × W × H)2085*1200*1274mm
(4)Engine Type:Water-cooled 500CC manual;
(5)single-cylinder:four-stroke;
(6)Fuel Type:unleaded petrol above 90 #
(7)Wheelbase:1400mm
(8)Max Load :570 kgs
(9)Engine Displacement:498ml
(10)Curb Weight:460kgs
(11)Engine Max Power:19.6kw (4500r/min ± 5%) kw / r / min
(12)The Max Speed:≥ 90km / h
(13)Brake Control Method (front / rear):hand / foot movement
(14)Engine Rated PowerCorresponding Speed:16kw (4500r/min ± 5%) kw / r / min
(15)Ignition mode:C.D.I
(16)Petrol tank capacity: 13L
17)Max Engine Torque Corresponding Rotational Speed:39N.m(2700~3000r/min ± 5%) nm/r/min
(18)Battery Specification:12V36Ah
(19)Transmission Output Mode: shaft drive
(20)Clutch Type:Single-plate, wet spring
(21)Stalls: 5 files. 2 forward, one back, a neutral gear, a parking stall
(22)Starting Way:Electric start pull start
(23)Idle Speed:1500 ± 150 r / min
(24)Oil Grade:SF 15W/40
(25)Drive Mode:Four Drivers
(26)Compression Ratio: 8.6:1
(27)Max Climbing Degree:30 degrees
(28)the Lowest Ruel Consumption Rate:> 329 g / kw/h
(29)Container: 20/40/40HQ 8/16/25PCS
