N1010-K-M1-SP cylindrical roller bearing Dimension:50x80x16mm,SP precision grade
N1010-K-M1-SP cylindrical roller bearing Dimension:50x80x16mm,SP precision grade
N1010-K-M1-SP cylindrical roller bearing Dimension:50x80x16mm,SP precision grade
N1010-K-M1-SP cylindrical roller bearing Dimension:50x80x16mm,SP precision grade
Specifications
Place of Origin :
Germany
Brand Name :
FAG
Model Number :
N1010-K-M1-SP
Certification :
ORIGINAL
Description


FAG bearings N1010-K-M1-SP

d: 50mm D: 80mm B: 16mm

Type:

N

Cylindrical roller bearing, single row, steel rollers, ribs on inner ring,

outer ring ribless

Dimension series:

10

Medium series

Dimension（dxDxb）

50x80x16mm

Tapered bore

K

Tapered bore(taper 1:12)

Cages:

M1

Brass cage,guided by rollers

Precision:

SP

Special precision

N1010-K-M1-SP High Precision roller Bearing, N1010KM1SP Machine tool main spindle bearing

N1010.K.M1.SP FAG High Speed roller Bearing, roller Bearing is Super precision single row cylindrical roller bearing with 1:12 tapered bore and brass cage, bearing is SP quality and made in Germany

Item: N1010-K-M1-SP FAG Cylindrical roller Bearing，FAG machine tool main spindle bearing

Type: super precision cylindrical roller Bearing

rolling: roller

Quality: SP Grade

Dimensions: 50mm x80mm x16mm /Metric

ID (inner diameter)/Bore: 50mm

OD (outer diameter): 80mm

Width/Height/thickness: 16mm

Size:50 x 80 x 16mm

Quantity: One Bearing

Dynamic load rating Cr: 36000 N

Static load rating Cor: 41500 N

Limiting Speed:

Grease Lubrication: 14000 RPM

Oil Lubrication: 16000 RPM

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required.

N1010-K-M1-SP cylindrical roller bearing Dimension:50x80x16mm,SP precision grade
