Industrial Plasma Cutting Machine 1530
Industrial Plasma Cutting Machine 1530
Specifications
Place of Origin :
China
Brand Name :
china coal
Model Number :
CG2-11
Certification :
MA, ISO9001, CE
Description

Features:

1.Function and Technical parameters instruction

Menu Chinese chart; Multilevel buttons operation; full screen text editor;

It can be cut arbitrarily complex shapes, real-time cutting trajectory and cutting speed;

Adopted International code live, data conversion, and to identify the G-code ESSI code;

It could modify the cutting code, and the corresponding one by one code to display graphics segment

It can be arranged in a matrix, staggered; can zoom, rotate, horizontal mirroring and vertical mirroring

Setting up the cutting speed, acceleration and Speed adjustment rate at the Background.

The workpiece kerf compensation;

It can accelerate in cutting processing immediately, backing up unlimited ,it could forward without I /O.

It can be realized forward, back and return to the origin, through gun in the Cutting parking.

Temporary exit, memory, the current split point, the next to be cut from the point of the memory;

Optional:

1.Different working size:/1500X3000MM /1600X4000MM or other sizes according to customers’ needs

2.Servo motors and drivers

3.Different power: 65A / 100A / 130A /200A for different thickness cutting

4.Torch Height control system.

Warranty:

1-2 years for machine,Lifelong after-sales service

Application

Processing shells of machinery and electronic products, advertising signs, crafts, iron garden, car manufacture, boat building, electrical accessories, board cutting.

1325

1530

X, Y axis traveling schedule

1300×2500mm

1500×3000mm

Z axis traveling schedule

0.5-50mm

Plasma electric current

15-200A

Maximumcarving speed

0-8m/min

0-8m/min

Maximum running rate

0-50m/min

0-50m/min

Power

8.5KW-10.5KW

8.5KW-10.5KW

Cutting thickness

0.5-8mm

0.5-8mm

Working voltage

380V

380V

Supply frequency

50HZ

50HZ

File transfer way

USB

USB

Striking the arc way

Non-contact striking the arc

Non-contact striking the arc
