| Feature of product | ||
| Quality,credit,Service,Value'is our core value | ||
| 1, LED | Energy saving | *Super bright led , lumen efficiency 130lm/w (LED) |
|
| *Choosing a narrow range of Bin to keep perfect color consistence (by ANSIC78.377A standard) | |
| 2, Driver | Good performance | * PF: 0.98, efficiency : 89% and THD<15% |
| Safty | *Constant current isolated circuit design; output voltage 30-40V, which is safe for man-touch; with over-current , overvoltage and short-circuit protection | |
| 3, Warranty | * 3 years warranty | |
| Model number | Specification | ||||||
| Dimension | Rated Power | Input Voltage | LED Chips | Lumens | CRI (Ra) | Efficiency of Light | |
| AOK-408 -10WR1 | 600mm*26mm & 2FT | 10W | AC100~277V 50~60Hz | 84pcs SMD2835 | 1000-1100LM | >80 | Clear lens: >105lm/W
Frosted lens: >95lm/W |
| AOK-408 -14WR1 | 900mm*26mm & 3FT | 14W | AC100~277V 50~60Hz | 132pcs SMD2835 | 1400-1580LM | >80 | |
| AOK-408 -20WR1 | 1200mm*26mm & 4FT | 20W | AC100~277V 50~60Hz | 180pcs SMD2835 | 2000*2150LM | >80 | |
| AOK-408 -25WR1 | 1500mm*26mm & 5FT | 25W | AC100~277V 50~60Hz | 216pcs SMD2835 | 2450-2550LM | >80 | |
| AOK-408 -30WR1 | 1800mm*26mm & 6FT | 30W | AC100~277V 50~60Hz | 264pcs SMD2835 | 2850-2950LM | >80 | |
