Outdoor messenger Aerial optic fiber cable GYXTY
Outdoor messenger Aerial optic fiber cable GYXTY
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-ABC IS
Installation :
Air Blown Cable
Sheath Material :
PE,LSZH
Fiber Number :
2~12
Operating temperature :
-40~+60°C
Loose Tube Material :
PBT
Fiber Type :
G652D,G657A,G655
Water-blocking Material :
YES
Cable Filling Compound :
YES
Messenger :
Steel Wire
Model :
Central Unitube
Certifications :
ISO9001,ROHS
Description

Description:Outdoor messenger Aerial optic fiber cable GYXTY

We are a manufacturer of optical cable in china with over 10 years of experience , we can provide high quality products.GYXTY optic fiber cable is one of our common products,we can ensure the quality for our experience.

Specifications

GYXTY outdoor fiber optical cable
Type: center tube type with two steel wires
The way: Aerial and duct
Waterblocking: jelly

Characteristics:

· Good mechanical and temperature performance

· High strength loose tube that is hydrolysis resistant

· Special tube filling compound ensure a critical protection of fiber

· Crush resistance and flexibility

· PSP enhancing moisture-proof

· Two parallel steel wires ensure tensile strength

· Small diameter, light weight and friendly installation

· Long delivery length

GYXTY outdoor fiber optical cable

  • The unique fiber excess length control method provides the cable with excellent tension and environmental properties
  • l The loose tube material itself have good water-resistant properties of solution and higher intensity, Special jelly filled in the loose tube provides the fibers with critical protection
  • l Excellent crush resistance performance and flexible performance
  • l The out PE sheath provides good anti-UV radiation performance
  • l Adopt the following measures to ensure the waterproof properties of optical fiber cable
  • l The unique waterproof compounds filled in the loose tube
  • l Safety-filled cable core

Application

Long haul and building network communication

Min bend radius(mm)

Shor-term 10D

Long-term 20D

The way

Duct/Aerial

Operating temperature (°C)

-40~60
Technical Parameter:

Cable Type

Fiber Count

Cable Diameter mm

Cable Weight kg/km

Tensile Strength

Crush Resistance

Bending Radius

Long/Short Term

Long/Short Term

Static/Dynamic

N

N/100mm

mm

GYXY

2~12

9.5

90

600/1500

300/1000

10D/20D

GYXY

2~12

10.2

100

1000/3000

1000/3000

10D/20D
