Fiber Optical Rodent Resistant Cable Outdoor Armored
Fiber Optical Rodent Resistant Cable Outdoor Armored
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-ABC IS
Installation :
Underground,Direct-buried
Sheath Material :
PE,LSZH
Fiber Number :
2~12
Operating temperature :
-40~+60°C
Loose Tube Material :
PBT
Fiber Type :
G652D,G657A,G655
Water-blocking Material :
YES
Cable Filling Compound :
YES
Messenger :
Double Jackets
Model :
rodent resistant cable
Certifications :
ISO9001,ROHS
Central Strength Member :
FRP
Description

Fiber Optical Rodent Resistant Cable

Description:

the cable is suitable for Aerial or Duct application, size of 2~288 cores, FRP CSM, armored with steel tape and PE outer sheath.

the cable is of very good tensile strength.

the cable is easy for installation.

Features:

  • Good mechanical and temperature performance
  • High strength loose tube that is hydrolysis resistant
  • Special tube filling compound ensure a critical protection of fiber
  • Crush resistance and flexibility
  • The following measures are taken to ensure the cable watertight:
  • Single Fiber Reinforced Plastic as the central strength member
  • Loose tube filling compound
  • 100% cable core filling

Optic Characteristics:

Fiber Type

G652

G655

50/125μm

62.5/125μm

Attenuation

(+20 oC)

850nm

No

No

≤3.0 dB/km

≤3.0 dB/km

1300nm

No

No

≤1.0 dB/km

≤1.0 dB/km

1310nm

≤0.36 dB/km

≤0.40 dB/km

No

No

1550nm

≤0.22 dB/km

≤0.23 dB/km

No

No

Bandwidth

(Class A)

850nm

No

No

≥600 MHz·km

≥200 MHz·km

1300nm

No

No

≥1200 MHz·km

≥600 MHz·km

Cable Cut-off Wavelength

≤1260nm

≤1450nm

No

No

Remarks: We can design oval cross section and non-metallic structure on requirement, e.g.:GYXTEW,GYFXTW,GYFXTEW, etc...

Packing: Non-fumigated Iron-wooden composite drum, or Fumigated wooden drum;

Drum length: 2km, 3km or 4km.
