Non-metallic Outdoor Communication Optical Cable GYFTA
Non-metallic Outdoor Communication Optical Cable GYFTA
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-GYFTA
Installation :
Duct,Aerial
Sheath Material :
PE,LSZH,PVC,TPU
Fiber Number :
12~288
Package :
2KM/3KM
Operating temperature :
-40~+60°C
OEM :
Available
Loose Tube Material :
PBT
Fiber Type :
single mode or multi mode
Water-blocking Material :
YES
Cable Filling Compound :
YES
Messenger :
FRP
Description

Non-metallic Outdoor Communication Optical Cable GYFTA

The fibers ,250 μm are positioned in a loose tube made of a high modulus plastic.The tubes are filled with a water-resistant filling compound.A Fiber Reinforced Plastic (FRP) locates in the center of core as a non-metallic strength member, the tubes (and fillers) are stranded around the strength member into a compact and circular core. After an Aluminum Polyethylene Laminate (APL) moisture barrier is applied around the cable core, the cable is completed with a PE sheath.

2. Main Mechanical Performance:

Item Unit Index
Fibre count 2-144
Max. tension Short terms N 1500
Long terms 600
Max. crush loading Short terms N/100mm 1000
Long terms 300
Min. bending radius Static Timea cable diameter 12.5
Dynamic 25
Reference diameter mm 12.6-16.1
Reference weight kg/mm 160-340
Temperature rage -40+60
Application For overhead and duct application

Standards

GYFTA cable complies with Standard YD/T 901-2001as well as IEC 60794-1.

Characteristics:

1)Good mechanical and temperature performance

2)High strength loose tube that is hydrolysis resistant

3)Special tube filling compound ensure a critical protection of fiber

4)Specially designed compact structure is good at preventing loose tubes from shrinking

5)PE sheath protects cable from ultraviolet radiation

6)The following measures are taken to ensure the cable watertight:

Single Fiber Reinforced Plastic as the central strength member

Loose tube filling compound

100% cable core filling

APL moisture barrier

We Produce:

1.Outdoor Fiber Optic Cable(GYXTW,GYFTY,GYTA,GYTS,ADSS,GYXTC8Y,GYTA53 etc.)

2.Indoor Fiber Optic Cable(Simplex/Duplex indoor cable,distribution box,break-out cable,waterproof cable etc.)

3.FTTH(bow-type access cable,self-supporting bow-type cable)

4.Fiber Patch Cord(SC,SC,LC,FC,MTRJ,MU etc.)

5.Accessories:Fiber Patch Panel,Fiber Splice Closure,Fiber Media Converter,Fiber Adapter
