Micro In/outdoor Optic Fiber Cable GY(F)XTY
Micro In/outdoor Optic Fiber Cable GY(F)XTY
Specifications
Place of Origin :
Shenzhen,China
Brand Name :
GT-Link
Certification :
ISO,CE,RoHS,GGS
Model Number :
GT-ABC IIS
Installation :
Aerial,Duct
Sheath Material :
PE,LSZH,PVC,TPU
Fiber Number :
2~12
Operating temperature :
-40~+60°C
Loose Tube Material :
PBT
Fiber Type :
9/125,50/125,62.5/125um
Water-blocking Material :
YES
Cable Filling Compound :
YES
Messenger :
Central Loose Tube
Model :
Steel Type
Description

Micro In/outdoor Optic Fiber Cable GY(F)XTY
1.Micro In/outdoor Optic Fiber Cable GY(F)XTY

2.Anti-electromagnetism ability

3.Quality Approvals,Customized

4.OEM,Good Price

Description :

The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.

l Technical Advantages :

  1. Good mechanical and temperature performance;
  2. High strength loose tube that is hydrolysis resistant;
  3. Special tube filling compound ensure a critical protection of fiber; Crush resistance and flexibility; Inexpensive and can reduce operating costs;
  4. Two parallel steel wires ensure tensile strength; Small diameter, light weight and friendly installation; Long delivery time
  5. Comply with standard YD/T, 1258.4-2005, IECA-596, GR-409, ICE 60794, etc.

l Application:

  1. Local area network system, CATV , fiber to the home cabling, indoor/outdoor cabling.
  2. Support more network increase service in future
  3. Subscribers network system
  4. Suitable for ducts and aerial
  5. Installation: wall, interlayer, pipe, trough, duct

In/outdoor Optic Fiber Cable GY(F)XTY Spec.:

Fiber count

Cable Diameter

(mm)

Cable Weight (kg/km)

Tensile (N)

Long/ Short term

Crush (N/100mm)

Long/ Short term

Min. Bend Radius (mm)

Dynamic/ Static

1~2

5.6±0.2

34

200/600

300/1000

20D/10D

3~6

6.0±0.2

38

200/600

300/1000

20D/10D

7~12

6.5±0.2

43

200/600

300/1000

20D/10D

Note: Range of temperature: -20~+60°C

Order Optional Info.:

l Jacket material: PVC (Environmental lame-retardant polyvinylchloride), LSZH (Environmental low smoke zero halogen flame retardant polyolefin), PE (Environmental polyethylene), or other customerized material.

l Jacket color: blue, orange, green, brown, gray, red, black, yellow, and violet, pink, aqua.

l Fiber type: B1-G.652, B1.3-G.652.D, B4-G655, A1-50/125μm, A1b-62.5/125μm, M1-Maxband 150, M3-Maxband 300, M5-Maxband 550, E1- EasyBad G.657, E1.1- EasyBad Plus G.657, etc.

l Cable Dimension: the nominal cable dimension, or other constomerized dimension;

l Fiber Count: total number of fibers in the cable

l MOQ: 1km~2km, or other customerized
