Model:ZW-NC535AIW-P

Catalogue

Type

Parameters

Features

View by phone

Support monitoring via mobile devices on line(such as iOS,Android OS)

View on PC

support windows system

Monitor Advantage

Support IPhone,Android,Computer monitor. Miscrosoft certification plugin, no virus risk.

Sever cluster

Using Amazon Cloud PnP servier cluster, Intelligent application and

super stable

UID Technology

UID scan technology applied, easy to operate, and highly confidential.

Easy operation

Plug & Play, technology, penetration degree can be 99%,applicable toany

complex network surroundings. Easy operation: 1. plug the cable and power line, 2.install computer software,

scan code to add camera.

Local Memory

Support 32G TF Cards

Super Client

1,4,9,16,25,36, 64,81-channel , no user limited , centralized monitor,

remote record and playback

System

Operation system

Embedded Linux OS

System security

Supports account, password authority management

DDNS

Free DDNS

Collection

Image sensor

1/4inch 720p Progressive Scan CMOS

SNR

≥39dB

Minimum Illumination

0.8Lux/F1.4(color mode),0.3Lux/F1.4(B&W mode)

3A

Auto White Balance,Auto Exposure,Automatic Gain

Lens/View Angle

4～9mm@F1.4/51～24˚ 3 x optical zoom

Video

Compression Format

H.264

Resolution

720P(1280*720)/VGA(640×480)/QVGA(320×240)

Maximum frame rate

0-30fps

Adjustment

light intensity,contrast ratio,saturation level are adjustable.

Nightvision

IR-CUT

Dual Filter,IR-Cut

Effect

Dual Filter,IR-Cut,12pcs 850nmΦ5mm IR LED,IR irradiation distance:10m

Memory

Memory Socket

Automatic pop-up slot for TF card

View by SD Card

Remote browsing, download of content from 32G tf card

Network

Socket

RJ-45 10/100Mb self-adaptable Ethernet slot

WIFI

WIFI 802.11 b/g/n

Visitors Online

Support 4 visitors viewing on line at the same time

P/T

Control Method

Pan Range:350°,Tilt Range:120°

Alarm

Alarm Detection

Support motion detecting

Physical index

Power

Typical:3.5W(IR LED turn on)/Max:7W(P&T turn on)

Comsumption

<6W

Temperature

-10~50℃

Humidity

10%~85%

Weight

Gross:1200g(Note: in kind prevail)

Package size

200×120×179mm(L×W×H)

Certification

Certificate

ISO FCC CE RoHS
