Key Features
Highlights MJPEG, CMOS Two-way audio, Mini style, Indoor 10 LED, IR distance 8~10M. Wireless(Wi-Fi/802.11/b/g) , Free Factory DDNS Motion detection, email alert, FTP upload Iphone, 3G phone, Smartphone supported Multi-language, Firefox, Safari, Google browser Mini Style: 80*44*80mm(GW:0.6kg)
Specifications
|
Image Sensor |
|
Style |
Mini |
|
Sensor |
CMOS |
|
Sensor Size |
1/4 Inch Color CMOS Sensor |
|
Resolution |
0.3 Megapixels |
|
Lens (mm) |
3.6 |
|
Viewing Angle (Degree) |
75 |
|
Minimum Illumination (Lux) |
0.5 |
|
Video Image/Audio Setting |
|
Compression |
MJPEG |
|
Video Frame Rate (FPS) |
30 |
|
Refresh Rate |
60HZ, Outdoor, 50HZ |
|
Video Adjustment |
Auto Backlight Compensation, Contrast Adjustable, Brightness Adjustable |
|
OSD |
Yes |
|
Audio Output |
External Speaker |
|
Audio Input |
Built-in Mic |
|
Audio Compression Standard |
ADPCM |
|
Communication&Interface |
|
Network Interface |
Wi-Fi/802.11/b/g, RJ-45 10/100Mb self-adaptable Ethernet slot |
|
Supported Protocol |
FTP, UPNP, HTTP, DHCP, DNS, PPPoE, DDNS, SMTP, TCP/IP |
|
Wireless Security |
WPA, WPA2, WEP |
|
IP Mode |
Static IP address, Dynamic IP address |
|
DDNS (Free) |
Yes |
|
Alarm Input |
1 On/Off Input |
|
Alarm Output |
1 Relay Output |
|
Alarm Action |
Email Photo, Local Alarm, FTP Photo |
|
Physical/Environment |
|
Environment |
Indoor |
|
Power Supply (V) |
5 |
|
Power Consumption (W) |
3 |
|
Operate Temperature (℃) |
(-10~+55) |
|
Size (L x H x W, mm) |
80x44x80 |
|
Weight (g) |
600 |
|
System Requirment |
|
Supported Mobile Systems |
Android, Symbian, Windows Mobile, iPhone OS |
|
Supported Operating Systems |
Microsoft Windows ME, Mac os, Microsoft Windows Vista, Microsoft Windows 2000, Microsoft Windows 98, Microsoft Windows 7, Microsoft Windows XP |
|
Supported Browers |
Google Chrome, Safari, Other Standard Browser, Firefox, IE |
|
Client Software |
Yes |
|
Additional Features |
|
Features |
Remote Access, Day Night, Motion Detection |
|
IR Night Vision Distance (m) |
8~10 |
|
Two-way Radio |
Yes |
|
User Account Setting (Level) |
3 |
|
Online User |
9 |
|
Update Firmware |
Yes |
|
Language |
Simplified Chinese, Français, Italian, Deutsch, España, Português, English |
|
What's in the box |
|
What's in the box |
IP camera, English User manual, Screew, Bracket, CD, Ethernet cable, Power adaptor |
