Customized Laser Module
Customized Laser Module
Specifications
Lifetime :
>8000Hrs
material :
brass or aluminum
Description

1,Customized Laser Module
2,high stability
3,high reliability
4,low consumption
5, mini size

1,Customized Laser Module

2,high stability

3,high reliability

4,low consumption

5, mini size

Including green, red & infrared (532nm, 635nm, 650nm, 780nm, 808nm, 830nm, 850nm, 980nm). Dot, line & cross laser module.

Application:

1. Industrial Instruments and Equipments

2. Wild Explore Instruments

3. Military Instruments and Equipments

4. Medical Instruments

Specifications

Spectral Range

Red

Infrared

Wavelength(nm)

635

650

780

808

850

980

Output power(nW)

5~40

5~150

5~150

100~30000

5~100

50~7000

Operating current(mA)

25(min)~5000(max)

DC Input Voltage (V)

2.6~5.5

Operating Temperature( Deg.C )

From -10 to 50

Storage Temperature

( Deg. C)

From -40 to 80

Power Stability via Operating Voltage

>95% ( @2.7~5.5VDC)

Power Stability via Operating Temperature

>90% (@-10°C~50°C)

MTTF (Hrs)

10000

Circuit Protection

Static, Surge, and Reverse Polarity Protected

Case Material

Brass or Aluminum

Output Beam

Dot, Line & Cross

Dot
