High Capacity Rotary Tube Furnace Calcining 8 R / Min Stable Temperature
High Capacity Rotary Tube Furnace Calcining 8 R / Min Stable Temperature
Specifications
Brand Name :
EasyFashion
Model Number :
GN5800C
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1 set
Price :
To be discussed
Payment Terms :
T/T, Western Union
Supply Ability :
15~25 sets per year
Delivery Time :
120~160 days
Packaging Details :
standard packing, wooden cases
Size(mm) :
Φ300×5800
Rotating speed of tube :
1~8 r/min
Max. working temperature(°C) :
700°C
Max. testing temperature(°C) :
900°C
Dimension（L×W×H） :
8100×1400×2750mm
Tilting angle of tube :
3°~6° adjustable
Description

Rotary-tube Calcining Furnace Rotary Tube Furnace High Capacity Stable Temperature

Features:
· The charging and discharging spirals of furnace tube adopt conversion frequency to control output and quality.

· Suitable for different products and quality.
· Energy saving, long service life, high production efficiency
· Stable temperature change, precision control, less error, high quality.

Technical specifications:

Model GN5800C GN6300C GN8000C
Size(mm) Φ300×5800 Φ400×6800 Φ400×8000
Power 90kW 140kW 300kW
Rated voltage 380V 50Hz, three-phase five-wire
Rotating speed of tube 1~8 r/min
Temperature control Three zones Four zones Four zones
Tilting angle of tube 3°~6° adjustable
Max. working temperature(°C) 700°C
Max. testing temperature(°C) 900°C
Powder recycling rate ≥95%
Dimension(L×W×H) 8100×1400×2750mm

10000×1780×3280

mm

 10500×1800×2890mm

Overview:

The equipment is mainly used for calcining of chemical and metal powders. For example, it can calcine APT to get WO3.
