50L Blending Spray Drying Equipment Z Type With Alcohol Recycling System
50L Blending Spray Drying Equipment Z Type With Alcohol Recycling System
Specifications
Brand Name :
EasyFashion Industry
Model Number :
GN050D
Certification :
CE Certificate
Place of Origin :
China
MOQ :
1 set
Supply Ability :
10 set per year
Delivery Time :
120 days
Packaging Details :
Standard packed by wooden cases and container.
Rated voltage :
380 V 50 Hz, three-phase five-wire
Rotary speed of blending shaft (Without loading) :
10～35r/min ( Adjustable)
Max. capacity :
35L
Working frequency :
10~50Hz ( Adjustable)
Ultimate vacuum :
-0.06MPa
Pumping rate :
0.84 m3/min
Description

50L Overall Function Z - type Blending Dryer For cemented Carbide Powder

1. Overview

The equipment consists of main body, vacuum pump, TCU, and alcohol recycling system..

The box of the equipment with double-walled water jacket is made of stainless steel. Specially, the inner wall is made of stainless steel with mirror surface.

There are two Z-type shafts, which are processed from two whole stainless steel forging.

2. Technical specifications

Model

 GN050D

Ultimate vacuum

-0.06MPa

Blending power

 1.5kW

Working frequency

10~50Hz

( Adjustable)

Power of vacuum pump

 3KW

Pumping rate

 0.84 m3/min

Max. capacity

 35L

Rated voltage

 380 V 50 Hz, three-phase five-wire

Max. blending weight

50 kg/run
