1.5kw Powder Manufacturing Equipment 35L Capacity With Two Z - Type Shafts
1.5kw Powder Manufacturing Equipment 35L Capacity With Two Z - Type Shafts
Specifications
Brand Name :
EasyFashion
Model Number :
GN050D
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1 set
Price :
To be discussed
Payment Terms :
T/T, Western Union
Supply Ability :
15~25 sets per year
Delivery Time :
90~160 days
Packaging Details :
standard packing, wooden cases
blending power :
1.5kw
working frequency :
10-50Hz(Adjustable)
power of vacuum pump :
3kw
pumping rate :
0.84 m3/min
max.capacity :
35L
Description

Z-type blending dryer

1. Overview

Z-type blending dryer integrates functions of blending, stirring, drying, and medium recycling.

The equipment consists of main body, electric system, vacuum pump, TCU, and alcohol recycling system.

The box of the equipment with double-walled water jacket is made of stainless steel. Specially, the inner wall is made of stainless steel with mirror surface.

There are two Z-type shafts, which are processed from two whole stainless steel forging. The gap between two shafts, and between shafts and box inner wall, could both reach 2-3mm.

2. Technical specifications

Model

 GN050D GN300D

Rated voltage

380 V 50 Hz, three-phase five-wire

Rotary speed of blending shaft (Without loading)

10~35r/min

( Adjustable)

10~18r/min

( Adjustable)

Blending power

 1.5kW 7.5kW

Working frequency

10~50Hz

( Adjustable)

Power of vacuum pump

 3KW 5.5KW

Pumping rate

 0.84 m3/min 2.1 m3/min

Max. capacity

 35L 240L

Ultimate vacuum

 -0.06MPa -0.08MPa

Max. blending weight

50 kg/run

300 kg/run
