90 X 120 Hot Zone Vacuum Heat Treatment Furnace Vacuum Hot Press Furnace
90 X 120 Hot Zone Vacuum Heat Treatment Furnace Vacuum Hot Press Furnace
Specifications
Brand Name :
EasyFashion
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1 set
Price :
To be discussed
Payment Terms :
T/T, Western Union
Supply Ability :
2-10 sets per year
Delivery Time :
180 working days
Packaging Details :
standard packing, wooden cases
Rated power :
25
Max. working temperature :
2000°C
Hot zone :
90x120
Ultimate vacuum :
5x10-3 Pa
Max. pressure :
10T
Description

Vacuum Hot Press Furnace

Overview

The vacuum hot press furnace is batch type furnace and heating methods include graphite heating, molybdenum heating and medium frequency heating. This sintering furnace is well-suited for hot pressure sintering of hard alloy, functional ceramic and powder metallurgy in high temperature and high vacuum/protective gas. The output products are highly compacted to prevent deformation. The crystal grain of nanometer materials can be restrained to grow.

Technical specifications

Model Rated power Max. working temperature Hot zone Ultimate vacuum Max. pressure Stroke
EF-25-20Y 25kW 2000°C 90 ×120 5 ×10-3 Pa 10T 100mm
EF-40-20Y 40kW 2000°C 160 ×160 5 ×10-3 Pa 20T 100mm
EF-30-16Y 30kW 1600°C 150 ×200 6 ×10-4 Pa 20T 150mm
EF-18-10Y 18kW 1000°C 200 ×200 5 ×10-4 Pa 20T 150mm
EF-63-20Y 63kW 2000°C 250 ×250 5 ×10-3 Pa 30T 100mm
EF-50-22Y 50kW 2200°C 150 ×180 5 ×10-4 Pa 10T 100mm
EF-150-26Y 150kW 2600°C 300 ×300 10Pa 100T 150mm

Features

1. Double-layer water jacket cooled structure on furnace shell to improve cooling rate.

2. Suitable distribution of heating elements (graphite, molybdenum or induction heating) to improve heat uniformity.

3. Dedicated design on furnace structure to reduce evacuation time.

4. High automation and safe operation. The control system has the sound and light alarms and protection functions of abnormal phenomena such as water break, over-temperature, over-current and automatic switch failure of thermocouple.
