Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm
Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm
Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm
Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm
Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm
Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm
Specifications
Place of Origin :
Zhejiang, China
Brand Name :
DOWELL
Certification :
CE
MOQ :
1000 pieces
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 PCS Per 7 Days
Delivery Time :
7-15 Days
Insertion Loss :
<0.3dB
Return Loss :
>35dB
Operating Temperature :
-40 C- +75 ℃
Storage Temperature :
－40～＋85 ℃
Connection Times :
>1000
Connector :
LC, SC, ST, FC, MTP/MPO
Description

Multimode Duplex LC UPC To LC UPC OM4 Optic Fiber Patch Cord 3.0mm

Fiber optic patchcords and pigtails are components to link equipments and components in fiber optic network. There are many types according to different types of fiber optic connector including FC SV SC LC E2000n MTRJn MPO etc with single mode(9/125um) and multimode(50/125 or 62.5/125). Cable jacket material can be PVC, LSZH; OFNR, OFNP etc. There are simplex, duplex, multi fibers, Ribbon fan out and bundle fiber.

Specification:

Parameter Unit Mode PC UPC APC
Type
Insertion Loss dB SM <0.3 <0.3 <0.3
MM <0.3 <0.3
Return Loss dB SM >50 >50 >60
MM >35 >35
Repeatability dB Additional loss<0.1db, return loss< 5 dB
Interchangeability dB Additional loss<0.1db, return loss< 5 dB
Connection Times times >1000
Operating Temperature °C -40 C- +75 C
Storage Temperature °C -40 C- +85 C

Features:

1.1 Core Diameter:
Typically 50µm or 62.5µm (much larger than single-mode fiber’s 9µm core).
Allows multiple light modes (light paths) to propagate, leading to modal dispersion over long distances.
1.2 Distance & Bandwidth:
Optimized for short-range communication (up to 550m for 10Gbps, 1km for 1Gbps).
Higher attenuation compared to single-mode fiber, limiting long-distance use.
1.3 Common Standards & Types:
OM1 (62.5/125µm): Orange jacket, supports 1Gbps up to 275m.
OM2 (50/125µm): Orange jacket, improved bandwidth over OM1.
OM3 (50/125µm, laser-optimized): Aqua jacket, supports 10Gbps up to 300m.
OM4 (50/125µm, enhanced): Aqua jacket, supports 10Gbps up to 550m and 40/100Gbps.
OM5 (50/125µm, wideband): Lime green jacket, supports wavelength division multiplexing (WDM).
1.4 Connector Types:
LC, SC, ST, FC, MTP/MPO (for high-density connections).
Polished finishes (UPC or APC) for low insertion loss.

Application:

2.1 Data centers (server-to-switch connections).
2.2 Local Area Networks (LANs).
2.3 CCTV and video surveillance.
2.4 Medical imaging and industrial systems.
