ADSS Figure-8 Cable Suspension Clamp For Pole Mounting On Hook
ADSS Figure-8 Cable Suspension Clamp For Pole Mounting On Hook
ADSS Figure-8 Cable Suspension Clamp For Pole Mounting On Hook
ADSS Figure-8 Cable Suspension Clamp For Pole Mounting On Hook
Specifications
Model Number :
DW-1096
Place of Origin :
Zhejiang, China
Brand Name :
DOWELL
Supply Ability :
5000PCS Per 7 Days
MOQ :
1000 pieces
Payment Terms :
T/T, Western Union, Paypal
Delivery Time :
7-15 Days
Capacity :
7-11 mm FRP
Type :
Pole Mounting on Hook
Material :
UV resistant thermoplastic
Description

Suspension Clamps For Fig-8 Cable

The suspension clamps are designed to provide an articulated suspension for figure-8 cables with steel or dielectric insulated messenger on access network with spans up to 90m. Its unique patented design has been developed to offer an universal hardware fitting covering all suspension cases on wooden, metal or concrete poles. With straight grooves and a reversible system, these clamps are compatible with messengers diameters from 3 to 7mm and 7 to 11mm.

Specification:

MODEL MESSENGER MATERIAL Weight
JAWS REINFORCING PLATES SCREWS
DW-1096-1 Small groove: 3-5mm
Large groove: 5-7mm		 UV resistant
thermoplastic		 Hot-dip galvanised steel 0.22kg
DW-1096-2 Small groove: 7-9mm
Large groove: 9-11mm

Features:

1.1 Covers all messenger sizes from 3 to 11mm
1.2 Acts as a fuse to avoid damage on the cable in case of abnormal vertical overload (tree, car crash ...)
1.3 4kV dielectric insulation between the cable messenger and the pole/clamp
1.4 Central hole allowing installation on hooks so to provide a flexible suspension point and give extra protection against wind induced vibrations
Installation:

2.1 On a hook bolt: The clamp can be installed on a 14mm or 16mm hook bolt on drillable wooden poles. The length of the hook bolt depends on the pole diameter.

2.2 On a pole bracket with a hook bolt: The clamp can be installed on wooden poles, round concrete poles and polygonal metallic poles by using a suspension bracket CS, a hook bolt BQC12x55 and 2 pole bands 20 x 0.4mm or 20 x 0.7mm.

ADSS Figure-8 Cable Suspension Clamp For Pole Mounting On Hook

Application:

3.1 Designed for ducts with a Fiber Reinforced Plastic (FRP) messenger figure-8 shaped duct assembly.
