PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
Specifications
Model Number :
DW-M1X8
Place of Origin :
Zhejiang, China
Brand Name :
DOWELL
Supply Ability :
500 PCS Per 7 Days
MOQ :
500 pieces
Payment Terms :
T/T, Western Union, Paypal
Delivery Time :
7-15 Days
Diameter :
0.9mm
Material :
Hytrel、PVC、LSZH or customized
Humidity :
≤95%（+40℃）
Color :
Yellow or Cusomized
Operating temp :
-40~85℃
Storage temp :
-40~85℃
Description

PVC LSZH 1X8 Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector

A Mini Type PLC Splitter is a compact version of a Planar Lightwave Circuit (PLC) splitter, designed for space-saving installations in fiber optic networks. PLC splitters are passive optical devices that evenly divide an input optical signal into multiple output signals, commonly used in FTTH (Fiber-to-the-Home), PON (Passive Optical Network), and other fiber distribution systems.

Specification:

nx2, nx4, nx8 1x16 2x16,nx32 nx64 Tube type
L(mm) 55 60 60 80 100 diameter:Φ0.9mm or customized
W(mm) 7 7 12 20 40 Material: Hytrel,PVC,LSZH or customized
H(mm) 4 4 4 6 6 Color:blue, orange, green, brown, grey, white, red, black, or customized

PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector

Features:

1.1 Compact Size – Smaller than standard PLC splitters, making them ideal for high-density installations.
1.2 High Reliability – Uses PLC technology for stable performance with low insertion loss.
1.3 Uniform Splitting – Evenly distributes optical power across all output ports (e.g., 1×4, 1×8, 1×16, 1×32, 1×64).
1.4 Low Insertion Loss – Typically ranges from 3.6 dB (1×2) to ~21 dB (1×64).
1.5 Wide Operating Wavelength – Supports 1260–1650 nm, compatible with single-mode fibers.
1.6 Various Packaging Options:
Bare Fiber (Mini Blockless)
ABS Module (Box Type)
LGX Cassette (Rack-Mountable)
Fanout / Steel Tube Type

Common Split Ratios​:

2.1 1×2, 1×4, 1×8, 1×16, 1×32, 1×64
2.2 2×4, 2×8, 2×16, 2×32, 2×64 (for redundancy)

Applications:
3.1 FTTH (Fiber-to-the-Home) Networks
3.2 PON (GPON, EPON, XGSPON) Systems
3.3 CATV & Telecommunication Distribution
3.4 Data Centers & Local Area Networks (LAN)PVC LSZH Fiber Optic PLC Splitter Mini Type 1m, 1.5m With SC UPC Connector
