Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm
Specifications
Model Number :
DW-1041
Place of Origin :
Zhejiang, China
Brand Name :
DOWELL
Packaging Details :
Single item
Supply Ability :
5000PCS Per 7 Days
MOQ :
500 pieces
Payment Terms :
T/T, Western Union, Paypal
Delivery Time :
7-15 Days
Insertion Loss :
<0.3dB
Return Loss :
>35dB
Operating Temperature :
-40 to ~+ 75 ℃
Storage Temperature :
－40 ℃～＋85 ℃
Connection Times :
>1000
Mode Type :
MM
Description

Indoor LC PC Duplex Fiber Optic Multimode Patch Cord 3.0mm

A Fiber Optic Multimode Patch Cord (also called a multimode fiber jumper) is a short, flexible cable with connectors on both ends, used to connect optical devices in high-speed data communication networks. It is designed for short-distance, high-bandwidth applications, commonly found in data centers, LANs (Local Area Networks), and enterprise networks.

Specification:

Parameter Unit Mode PC UPC APC
Type
Insertion Loss dB SM <0.3 <0.3 <0.3
MM <0.3 <0.3
Return Loss dB SM >50 >50 >60
MM >35 >35
Repeatability dB Additional loss<0.1db, return loss< 5 dB
Interchangeability dB Additional loss<0.1db, return loss< 5 dB
Connection Times times >1000
Operating Temperature °C -40 C- +75 C
Storage Temperature °C -40 C- +85 C

Features:

1.1 Fiber Type – OM1, OM2, OM3, OM4, or OM5 (supporting different bandwidths and distances):
OM1 (62.5µm) – Up to 275m @ 1Gbps
OM2 (50µm) – Up to 550m @ 1Gbps
OM3 (50µm, laser-optimized) – Up to 300m @ 10Gbps
OM4 (50µm, enhanced bandwidth) – Up to 400m @ 10Gbps
OM5 (50µm, wideband multimode) – Supports SWDM for 40G/100G

1.2 Core Diameter – Typically 50µm or 62.5µm, allowing multiple light modes to propagate.

1.3 Jacket Types –
PVC (general indoor use)
LSZH (Low Smoke Zero Halogen) – For fire safety in data centers
Armored – Extra protection in harsh environments

Application:

2.1 Telecommunication Network

2.2 Fiber Broad Band Network

2.3 CATV system

2.4 LAN and WAN system

2.5 FTTP
