DE2290D SDK Support USB Barcode Scanner Module with 300 scans/sec Speed 300,000 Pixel CMOS and 3mil/0.076mm Reading Precision

Specifications

MOQ :

Model NO. :

DE2290D

Interface Type :

USB

Scan Speed :

300 scans/sec

Scan Element :

CMOS

Pixel :

300,000 Pixel, 640*480

Reading Precision :

3mil/0.076mm

Depth of Field :

30mm~550mm

Decoding Speed :

65cm/S

Scan Mode :

Manual, Continuous, Auto Sense, Command Control

Prompt Method :

LED Indicator Light, Buzzer

Print Contrast :

20%

Ambient Light :

Dark Environment, Indoor Natural Light

Weight :

3.5g

Dimension :

21.35mm L *15.50mm W * 11.40mm H

Interface :

FPC 12pin Pitch 0.5

Description

SDK Support USB Qr Code 1d 2D Barcode Scanner Module Engine

DE2290D is a high-performance 300,000 global pixel embedded 2D image module with advanced CMOS image recognition technology, intelligent image recognition system.

With excellent reading performance, you can easily read barcodes on media such as paper, merchandise, and screen.

The integrated compact design allows for easy insertion into a wide range of equipment.

Widely used in various types of self-service machines, price checking machines, lockers,etc.

DE2290D SDK Support USB Barcode Scanner Module with 300 scans/sec Speed 300,000 Pixel CMOS and 3mil/0.076mm Reading Precision

Communication	USB(USB-KBW,USB-COM,HID-POS),TTL
Scan Type	CMOS,Global shutter
Resolution	300,000 pixel, 640*480
Reading precision	≥3mil/0.076mm(PCS90%,CODE 39)
Depth of field	30mm~550mm(Different barcode range)
Decoding speed	65CM/S
Scan Mode	Manual , Continuous, Auto Sense, Command control
Prompt method	LED indicator light, buzzer (external circuit)
Field of view	41° * 31°
Scan angle	Test Conditions:CODE39,10mil/0.25mm,PCS90%
	Roll: ±360°,Pitch:±60°,Skew: ±55°
Print Contrast Signal	≥20%
Ambient Light	Dark environment, indoor natural light
Symbologies	1D:UPC-A,UPC-E,EAN-8,EAN-13,Code 128, GS1-128, Code 39,Code 32, Code 93,Code 11,Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5(Straight 2 of 5),Standard 2 of 5(IATA 2 of 5),Codabar(NW-7), MSI,GS1 Databar(Omnidirectional, Limited, Expanded),China Post, Tepepen, Febraban Brazil Bank Code,GS1 Composite, etc. 2D: QR Code, Micro QR Code, Data Matrix,PDF417, Micro PDF 417, MaxiCode, Aztec,HanXin Code, Japan post, Postnet, etc.

DE2290D SDK Support USB Barcode Scanner Module with 300 scans/sec Speed 300,000 Pixel CMOS and 3mil/0.076mm Reading Precision

Q1: How do you make sure the high quality barcode scanner?
DYscan: we are pofessional manufacturer and developer of barcode scanner, with rich field experience for 18 years.
Professional QC team and testing machine (Engine age test,wire bend machine,switch life test,shock resistance test).
All our barcode scanners pass CE,FCC,ROSH certifications etc.

Q2: How do you make quality control?
DYscan: we have wire bend test 1 million times, buttons are tested 1 million times, all the devices will be tested before send out.

Q3: How long is the warranty time of barcode scanner?
DYscan: 12 months

Q4: How to control the performance stable?
DYscan: We take the flow line production in the whole processing. Every product will be tested 4 times at least before delivery.

Q5: Can you provide OEM or ODM service for barcode scanner?
DYscan: We can do OEM, such as printing your own logo, color box, user manual. And we have our own technical team to support ODM service.

Q6: What are your strengths?
DYscan: We are a professional scanner manufacturer. The company is divided into different departments, each with its own director. The R&D department is responsible for the development of new products. The production department is responsible for the production and testing of products. The Marketing and Sales department consists of the sales team, and customer services.

Q7: Do I need to install drivers?
DYscan: No. Our scanners support plug and play. No drivers need to be installed. It can be used in Windows, Mac OS, IOS, Linux, UNIX, Android, etc.
