2205 / 2507 Duplex Stainless Steel Welded Tube For Condenser
2205 / 2507 Duplex Stainless Steel Welded Tube For Condenser
2205 / 2507 Duplex Stainless Steel Welded Tube For Condenser
2205 / 2507 Duplex Stainless Steel Welded Tube For Condenser
Specifications
Brand Name :
MTSCO
Model Number :
MTSCOSSWT63
Certification :
ISO 9001 & PED & AD2000
Place of Origin :
CHINA
MOQ :
negotiable
Price :
2500-12000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
500 Tons / Month
Delivery Time :
25 Days
Packaging Details :
Plywood Case / Bundles
Material :
duplex steel
Surface :
400 # Outside Polished
Length :
According to customer's requirement
Type :
Welded
Process Method :
ERW , EFW Etc
PMI Test :
100%
Description

2205 / 2507 Duplex Stainless Steel Welded Tube For Condenser

a) OD ( Outer Diameter ) : 9.5mm to 114.3mm

b) WT ( Wall Thickness ) : 0.8mm to 3.05mm

c) Length : According to customer's requirement

d) Standards : ASTM A312; ASTM A269; ASTM A789; ASTM A790 ect

e) Process Method : ERW, EFW etc

UNS Designation C Si Mn P S Cr Ni Mo N Cu
max max max max max
S31803 0.03 1 2 0.03 0.02 21.0 - 23.0 4.5 - 6.5 2.5 - 3.5 0.08 - 0.20 -
S32205 0.03 1 2 0.03 0.02 22.0 - 23.0 4.5 - 6.5 3.0 - 3.5 0.14 - 0.20 -
S32750 0.03 0.8 1.2 0.035 0.02 24.0 - 26.0 6.0 - 8.0 3.0 - 5.0 0.24 - 0.32 0.5 max
S32760 0.05 1 1 0.03 0.01 24.0 - 26.0 6.0 - 8.0 3.0 - 4.0 0.20 - 0.30 0.50 -1.00

2205 / 2507 Duplex Stainless Steel Welded Tube For Condenser

Industry & Advantage Application a) Petroleum
b) Chemical industry
c) Instrument
d) Industrial transportation
e) Mechanical structure industry
f) Need high corrision ability pipe's industry, such as offshore industry etc
Advantages a) Superior surface finish,
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Terms & Conditions Price Item FOB, CFR, CIF or as negotiation
Payment T/T, LC or as negotiation
Delivery Time 30 working days after received your deposit (Normally according to the order quantity)
Package Iron case; woven bag or as per customer’s requirement
Quality Requirement Mill Test Certificate will be supplied with shipment, Third Part Inspection is acceptable
Quality Test NTD(Ultrasonic test, Eddy Current test);
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test);
Metal Test(Metallographic Analysis, Impact Test-High/low temperature);
Chemical Analysis(Photoelectric Emission Spectroscopic)
Market Main Market Europe, Middle East, Southeast Asia, South America. etc

MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc . In order to facilitate customers , we have welded pipes and tubes too . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement . According to standard very strictly , tubes which produced by us always have correct OD and WT tolerance . The tolerance control is strictly accordance to produce standards . Our products are always satisfied with customers . Customers purchased our products created more profits .
