EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild
Specifications
Brand Name :
MTSCO
Model Number :
MTSCOSSCT13
Certification :
ISO 9001 & PED
Place of Origin :
CHINA
MOQ :
negotiable
Price :
5500-10000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
300 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Iron Case / Plywood Case
Material :
300 Series
Standard :
ASTM A269 / ASTM A213 / ASTM A312 / EN10216-5 Etc
Delivery Condition :
Soft / Hard
Every Coil :
About 30Kgs Per / Coil
Type :
Seamless
Surface :
Bright Annealed / Pickled
Description

EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface , For Fuild

Where the coiled tubing used ?

1 . Control tubing in oil and gas well
2 . Instrument tubing
3 . Chemicl injection tubing line
4 . Pre-insulated tubing
5 . Electric heating or steam heating tubing line
6 . Hater tubing line

EN10216-5 Chemical Composition :

Steel Grade C Si Mn P S N Cr Cu Mo Nb Ni Ti Others
max 　 　 max max 　 　 　 　 　 　 　 　
Steel Name Steel Number 　 　 　 　 　 　 　 　 　 　 　 　 　
X2CrNi19-11 1.4306 0.03 ≤1 ≤2 0.04 0.015 ≤0.11 18.00 - 20.00 - - - 8.00 - 10.00 - -
X5CrNi18-10 1.4301 0.07 ≤1 ≤2 0.04 0.015 ≤0.11 17.00 - 19.50 - - - 8.00 - 10.50 - -
X6CrNiTi18-10 1.4541 0.08 ≤1 ≤2 0.04 0.015 ≤0.11 17.00 - 19.00 - - - 9.00 - 12.00 5xC to 0.70 -
X6CrNiNb18-10 1.4550 0.08 ≤1 ≤2 0.04 0.015 - 17.00 - 19.00 - - 10xC to 1.00 9.00 - 12.00 - -
X2CrNiMo17-12-2 1.4404 0.03 ≤1 ≤2 0.04 0.015 ≤0.11 16.50 - 18.50 - 2.00 - 2.50 - 10.00 - 13.00 - -
X5CrNiMo17-12-2 1.4401 0.07 ≤1 ≤2 0.04 0.015 ≤0.11 16.50 - 18.50 - 2.00 - 2.50 - 10.00 - 13.00 - -
X6CrNiMoTi17-12-2 1.4571 0.08 ≤1 ≤2 0.04 0.015 - 16.50 - 18.50 - 2.00 - 2.50 - 10.50 - 13.50 5xC to 0.70 -

Stanard Wire Gauge ( Fomerly Imperial Wire Gauge ) SWG
SWG Wall Thickness SWG Wall Thickness
0 0.324 8.23 21 0.032 0.81
1 0.3 7.62 22 0.028 0.71
2 0.276 7.01 23 0.024 0.61
3 0.252 6.4 24 0.022 0.56
4 0.232 5.89 25 0.02 0.51
5 0.212 5.38 26 0.018 0.46
6 0.192 4.88 27 0.0164 0.42
7 0.176 4.47 28 0.0148 0.38
8 0.16 4.06 29 0.0136 0.35
9 0.144 3.66 30 0.0124 0.31
10 0.128 3.25 31 0.0116 0.29
11 0.116 2.95 32 0.0108 0.27
12 0.104 2.64 33 0.01 0.25
13 0.092 2.34 34 0.0092 0.23
14 0.08 2.03 35 0.0084 0.21
15 0.072 1.83 36 0.0076 0.19
16 0.064 1.63 37 0.0068 0.17
17 0.056 1.42 38 0.006 0.15
18 0.048 1.22 39 0.0052 0.13
19 0.04 1.02 40 0.0048 0.12
20 0.036 0.91 　 　 　

EN10216-5 300 Series Stainless Steel Coiled Tubing Bright Annealed Surface For Fuild

MTSCO is a leading manufacturer who is specialized in seamless coiled tubing produce . Stainless steel seamless coiled tubing final surface is bright annealed. According to standard very strictly, tubes which produced by us always have correct OD and WT tolerance. They are very popular in military, semiconductor, pharmaceutical biotechnology, precision instruments, hydraulic parts, chemicals industry, boilers and heat exchangers, aerospace industry, automotive industry, electronics, petroleum exploration, precision machinery, rail transportation, shipbuilding plants, air-conditioning industry, solar industry, water heater industry etc. They can be used in many others industries also .
