Specifications
Brand Name :
MTSCO
Model Number :
MTSCONAT11
Certification :
ISO 9001 & PED
Place of Origin :
CHINA
MOQ :
negotiable
Price :
25000-100000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
300 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Plywood Case
Material :
Inconel 625 , Alloy 625 , Nickel 625 Etc
Type :
Seamless
Technology :
Cold Drawn / Cold Rolled
Delivery Condition :
Soft / Hard
NDT :
Eddy Current Or Hydraulic Test
Inspection :
100%
Description

ASTM B444 / ASME SB444 Nickel Alloy Tubing 14BWG / 18BWG / 20BWG

1. Grade :UNS N06625 , N06600 ,N06601 , N07718 , N10276 ,N08800 , N08825 , N04400 ; etc

2 . OD ( Outer Diameter ) : 3.18mm to 101.6mm

3 . WT ( Wall Thickness ) : 0.5mm to 20mm

4 . Length : As customer's requirement

5 . Standard : ASTM B163; ASTM B167; ASTM B444; ASTM B622 etc

6 . Technology : Cold Drawn / Cold Rolled




Test :

1 . NTD(Ultrasonic test, Eddy Current test)

2 . Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test)

3 . Metal Test(Metallographic Analysis, Impact Test-High/low temperature)

4 . Chemical Analysis(Photoelectric Emission Spectroscopic)

MTSCO is a leading manufacturer who is specialized in stainless steel seamless pipes , bright annealed tubes , seamless coiled tubing etc basic products . We also have duplex stainless steel tubes and pipes , nickel alloy tubes and pipes etc . MTSCO has the most advanced producing and testing equipment . We can totally satisfy your requirement . According to standard very strictly, nickel alloy tubes which produced by us always have correct OD and WT tolerance . Nickel alloy tubes have a very important position in thermocouple & cable industry .

Main market or alloy tube include Europe , Middle East , Southeast Asia , South America , etc . MTSCO has bright annealing alloy tube and pickling alloy tube . Compared these two kinds of tubes , bright annealed alloy tubes are more popular in the market . Because it has bright out and inner surface .

ASTM B444 Standard
UNS N06625 Elements
Nickel : 58.0 min
Chromium : 20.0 min 23.0 max
Manganese : 0.5 max
Molybdenum : 8.0 min 10.0 max
Cobalt ( If Determined ) : 1.0 max
Aluminum : 0.40 max
Carbon : 0.10 max
Copper : …
Silicon : 0.5 max
Titanium : 0.40 max
Columbium : …
Columbium + Tantalum : 3.15 min 4.15 max
Sulfur : 0.015 max
Phosphorus : 0.015 max

Birmingham Wire Gauge BWG
　 Wall Thickness 　 Wall Thickness
BWG IN MM BWG IN MM
0 0.340 8.64 19 0.042 1.07
1 0.300 7.62 20 0.035 0.89
2 0.284 7.21 21 0.032 0.81
3 0.259 6.58 22 0.028 0.71
4 0.238 6.05 23 0.025 0.64
5 0.220 5.59 24 0.022 0.56
6 0.203 5.16 25 0.020 0.51
7 0.180 4.57 26 0.018 0.46
8 0.165 4.19 27 0.016 0.41
9 0.148 3.76 28 0.014 0.36
10 0.134 3.40 29 0.013 0.33
11 0.120 3.05 30 0.012 0.30
12 0.109 2.77 31 0.010 0.25
13 0.095 2.41 32 0.009 0.23
14 0.083 2.11 33 0.008 0.20
15 0.072 1.83 34 0.007 0.18
16 0.065 1.65 35 0.005 0.13
17 0.058 1.47 36 0.004 0.10
18 0.049 1.24 　 　 　
