Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
Specifications
Brand Name :
MTSCO
Model Number :
MTSCOHET09
Certification :
ISO 9001 & PED
Place of Origin :
CHINA
MOQ :
negotiable
Price :
3700-9000USD/TON
Payment Terms :
T / T ; L / C
Supply Ability :
300 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Plywood Case
Material :
TP304 TP316 , 300 Series Stainless Steel
Type :
Seamless
Lenght :
6096mm Straight Length
Delivery Condition :
Soft / Hard
NDT :
Eddy Current Or Hydraulic Test
Inspection :
100%
Description

Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L

ASTM A 213 / A 213M ASME SA213 / SA213M Specification for Seamless Ferric and Austenitic Alloy -Steel Boiler , Su[perheater , and Heat-Exchanger Tubes
ASTM A 249 / A 249M Specification for Welded Austenitic Steel Boiler , Superheater , Heat-Exchanger , and Condenser tubes

Size

OD : 25.4mm

WT : 2.11

Length : 12192mm

Advantage

Superior surface finish , better mechanical property ; more precise dimension ; perfect inspection method and inspection equipment

Application

Boiler tube applies to petroleum , chemical industry , electric power , boiler , high temperature resistant , low temperature resistant , corrosion resistant . The size can be made according to the customers requirements . High pressure boiler pipe applies to container , petrochemical and so on . Note : Generally , high pressure boiler pipe’s working pressure above 9.88Mpa and working temperature between 450 to 650 .

Package

Plywood case

ASTM A213 / A213M Chemical Composition :

Elements 304L(wt%) S30403 304(wt%) S30400 316L (wt%) S31603 316 (wt%) S31600
(C) Carbon, max 0.035 0.08 0.035 0.08
(Mn) Manganese, max 2 2 2 2
(P) Phosphorus, max 0.045 0.045 0.045 0.045
(S) Sulfur, max 0.03 0.03 0.03 0.03
(Si) Silicon, max 1 1 1 1
(Ni) Nickel 8.0 - 12.0 8.0 - 11.0 10.0 - 14.0 10.0 - 14.0
(Cr) Chromium 18.0 - 20.0 18.0 - 20.0 16.0 - 18.0 16.0 - 18.0
(Mo) Molybdenum N/A N/A 2.0 - 3.0 2.0 - 3.0
(Fe) Iron Bal. Bal. Bal. Bal.
(Cu) Copper N/A N/A N/A N/A
(N) Nitrogen N/A N/A N/A

N/A

MTSCO heat exchanger tube with pickling and annealing surface is very popular in boilers and heat exchangers industry , water heater industry , air-conditioning industry etc . This kind of seamless tubes are have a very important position in our all products .

Stainless Steel Cold Drawn Tube ASTM A213 / ASME SA213-10a TP304L
