Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200
Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200
Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200
Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200
Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200
Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200
Specifications
Brand Name :
NO
Model Number :
DN80-DN1200
Certification :
ISO 2531
Place of Origin :
China
MOQ :
10 pcs
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
one container per half month
Delivery Time :
20 to 60 days
Packaging Details :
Package in wooden pallet
Material :
Ductile Cast Iron
Shape :
Bend
Connection :
Flange
Type :
Elbow
Standard :
ISO2531
Size :
DN80 to DN1200
Description

Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200

90 degree Double-flange long radius bend

Material Cast iron
Size DN40 to DN2600
Tensile strength 420MPa
Elongation ≥5%
Hardness ≤230HWB
Connetion Flange
Usage Pipe fitting

Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200

Ductile Iron Pipe Fittings 90 Degree Double Flange Long Radial Bend DN80 - DN1200

DN T L Weight(kg)
PN10 PN16 PN25
80 7 380 14.5 14.5 14.5
100 1.1 400 18 18 19
125 7.5 425 23.5 23.5 24.1
150 7.8 450 30.5 30.5 32.5
200 8.4 500 46.5 46 50
250 9 550 67 66 73.5
300 9.6 600 91 90.5 101
350 10.2 650 117 122 138
400 10.8 700 149 158 180
450 11.4 750 184 200 221
500 12 800 227 254 275
600 13.2 900 332 379 403
700 14.4 1000 466 489 /
800 15.6 1100 632 661 /
900 16.8 1200 816 854 /
1000 18 1300 1048 1117 /
1100 19.2 1400 1315 1385 /
1200 20.4 1500 1627 1737 /

Packaging Details

(1). We will pack your items by carton or plywood cases for exporting standard.
(2). We can also pack your items according to your requirements.
Our Service
1. Good quality and low price.
2. Good after-sale service.
3. Bring the finest goods to customer is our ultimate goal.
4. Products are exported to various countries.
